| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
202-4143
|
Solid caster wheel (gray) |
$135.96
|
2 |
|
usually ships 3-11 days |
2 |
202-2098
|
4 inch wheel (gray) |
$41.47
|
4 |
|
usually ships 3-11 days |
3 |
202-5183
|
Main frame |
$694.65
|
1 |
|
usually ships 1-5 days |
4 |
202-2820
|
Rear upright |
$668.36
|
1 |
|
usually ships 1-5 days |
5 |
202-2821
|
Support arm |
$65.45
|
1 |
|
usually ships 3-11 days |
6 |
202-3537
|
Frame bracket |
$47.30
|
1 |
|
usually ships 1-5 days |
7 |
202-5184
|
Right rear support bracket |
$132.66
|
1 |
|
usually ships 3-11 days |
8 |
202-5185
|
Left rear support bracket |
$132.66
|
1 |
|
usually ships 1-5 days |
9 |
202-2377
|
11 inch hinge |
$39.27
|
1 |
|
usually ships 1-5 days |
10 |
202-1487
|
Latch |
$25.19
|
2 |
|
usually ships 3-11 days |
11 |
202-3543
|
10-24 x 1 threaded stud |
$6.71
|
2 |
|
ships same day |
12 |
202-5105
|
1 inch rubber loop clamp |
$7.81
|
2 |
|
usually ships 1-5 days |
13 |
202-2817
|
Nut 10-24 nylock jam stainless steel |
$6.71
|
2 |
|
usually ships 1-5 days |
14 |
999-1036
|
Nut 8-32 hex NTM nylon insert jam lock stainless steel |
$0.99
|
4 |
|
ships same day |
15 |
999-0294
|
Nut 1/4-20 hex nylon lock type NE stainless steel |
$1.18
|
5 |
|
ships same day |
16 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
$0.99
|
20 |
|
ships same day |
17 |
999-1482
|
Nut 3/8-16 nylon lock stainless steel |
$1.06
|
6 |
|
ships same day |
18 |
999-1466
|
Nut 1/4-20 lock with external toothed lockwasher SS |
$0.99
|
2 |
|
ships same day |
19 |
999-0617
|
Washer 3/8 x 1 flat stainless steel |
$1.82
|
8 |
|
ships same day |
20 |
999-0358
|
Screw 8-32 x 5/8 pan head phillips stainless steel |
$0.99
|
4 |
|
ships same day |
21 |
202-2831
|
Screw 5/16-18 x 3/4 flat head socket stainless steel |
$5.50
|
1 |
|
usually ships 3-11 days |
22 |
202-2851
|
Bolt 1/4-20 x 5/8 inch carriage head stainless steel |
$5.50
|
1 |
|
usually ships 3-11 days |
23 |
999-1401
|
Bolt 1/4-20 x 1 carriage head stainless steel |
$1.23
|
2 |
|
ships same day |
24 |
999-0967
|
Bolt 5/16-18 x 3/4 carriage head stainless steel |
$2.16
|
10 |
|
ships same day |
25 |
999-9066
|
Bolt 5/16-18 x 1 carriage head stainless steel |
$1.34
|
7 |
|
ships same day |
26 |
202-2832
|
Bolt 3/8 - 16 x 1 carriage head stainless steel |
$5.50
|
6 |
|
usually ships 3-11 days |
27 |
202-3540
|
Bolt 3/8-16 x 4 carriage stainless steel |
$9.90
|
2 |
|
usually ships 1-5 days |
28 |
999-9071
|
Nut 3/8-16 nylon insert jam lock stainless steel |
$1.52
|
2 |
|
ships same day |
