| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
202-6342
|
Bracket, Roller |
$17.71
|
1 |
|
usually ships 8-12 days |
2 |
202-0756
|
Guide roller |
$28.16
|
2 |
|
usually ships 8-12 days |
3 |
202-5630
|
Soft draw latch |
$59.51
|
1 |
|
usually ships 8-12 days |
4 |
202-6982
|
Hinge, Inner Jaw, LH |
$36.41
|
1 |
|
usually ships 8-12 days |
5 |
202-3173
|
Clevis pin |
$6.71
|
1 |
|
usually ships 1-5 days |
6 |
999-6723
|
Bolt 5/8-11 x 7 hex head grade 5 zinc plated |
$12.54
|
1 |
|
ships same day |
7 |
999-0968
|
Nut 5/8-11 nylon insert jam lock zinc plated |
$2.27
|
1 |
|
ships same day |
8 |
999-0297
|
Bolt 1/4-20 x 1 hex head stainless steel |
$2.53
|
1 |
|
ships same day |
9 |
999-0609
|
Nut 1/4-20 hex stainless steel |
$0.99
|
1 |
|
ships same day |
10 |
999-0086
|
Nut 10-32 nylon insert lock zinc plated |
$0.99
|
2 |
|
ships same day |
11 |
999-0294
|
Nut 1/4-20 hex nylon lock type NE stainless steel |
$1.18
|
5 |
|
ships same day |
12 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
$0.99
|
4 |
|
ships same day |
13 |
999-1466
|
Nut 1/4-20 lock with external toothed lockwasher SS |
$0.99
|
9 |
|
ships same day |
14 |
999-1350
|
Screw 10-32 x 1/2 inch phillips pan head stainless steel |
$0.99
|
2 |
|
ships same day |
15 |
999-0963
|
Bolt 1/4-20 x 3/4 carriage head stainless steel |
$1.50
|
11 |
|
ships same day |
16 |
999-0967
|
Bolt 5/16-18 x 3/4 carriage head stainless steel |
$2.16
|
4 |
|
ships same day |
17 |
999-9066
|
Bolt 5/16-18 x 1 carriage head stainless steel |
$1.34
|
1 |
|
ships same day |
18 |
202-3129
|
Cotter pin |
$5.50
|
1 |
|
usually ships 8-12 days |
19a |
202-6366
|
Jaw, LH, 13 inch 21/23 Gallon |
$435.71
|
1 |
(26 inch) |
usually ships 8-12 days |
19b |
202-6379
|
Jaw, LH, 14 inch 21/23 Gallon |
$387.53
|
1 |
(28 inch) |
usually ships 8-12 days |
19c |
202-6368
|
Jaw, LH, 13 inch 16/17 Gallon |
$326.81
|
1 |
(26 inch 16 gallon) |
usually ships 8-12 days |
19d |
202-6382
|
Jaw, LH, 14 inch 16/17 Gallon |
$312.95
|
1 |
(28 inch 16 gallon) |
usually ships 8-12 days |
20a |
202-6370
|
Band, Jaw, 13 inch |
$79.97
|
1 |
(26 inch) |
usually ships 8-12 days |
20b |
202-6384
|
Band, Jaw, 14 inch |
$86.24
|
1 |
(28 inch) |
usually ships 8-12 days |
21a |
202-6338
|
Bracket, Roller, Jaw, 26 inch |
$29.37
|
1 |
(26 inch) |
usually ships 8-12 days |
21b |
202-6340
|
Bracket, Roller, jaw, 28 inch |
$27.39
|
1 |
(28 inch) |
usually ships 8-12 days |
21c |
202-6336
|
Bracket, Roller, Jaw, 26 inch |
$46.20
|
1 |
(26 inch 16 gallon) |
usually ships 8-12 days |
21d |
202-6337
|
Bracket, Roller, Jaw, 28 inch |
$39.71
|
1 |
(28 inch 16 gallon) |
usually ships 8-12 days |
22a |
202-6369
|
Curtain, Jaw, 13 inch |
$63.03
|
1 |
(26 inch) |
usually ships 8-12 days |
22b |
202-6383
|
Curtain, Jaw, 14 inch |
$68.64
|
1 |
(28 inch) |
usually ships 8-12 days |
