HERO Smaller Optional Tank Assembly

#PartDescriptionPriceReqNotesAvailability
1 202-3373 Drain hose cap $18.26 1 ships same day
2 202-3036 Strainer screen $41.80 1 usually ships 8-12 days
3 202-6302 Hose, Baffle to Tank $35.31 1 usually ships 8-12 days
4 202-2025 Hosebarb $21.23 1 usually ships 8-12 days
5 202-6360 Curtain, Splash $17.93 1 usually ships 8-12 days
6 202-3582 Drain hose assembly $74.03 1 usually ships 8-12 days
7 202-2025 Hosebarb $21.23 3 usually ships 8-12 days
8 202-2118 Hosebarb $23.87 1 usually ships 8-12 days
9 202-3322 Tomcat decal $18.70 1 usually ships 1-5 days
10 202-3023 Squeegee vacuum hose $33.77 1 ships same day
12 202-6941 Hose, Inner Tank $30.59 1 usually ships 8-12 days
13 202-6956 Bracket, Tank Strap $37.62 1 usually ships 8-12 days
14 202-6974 Soundeading Kit $64.02 1 usually ships 8-12 days
15 202-7054 Lid,Screw-On,Tank $130.46 1 usually ships 8-12 days
16 202-0436 Tomcat front decal $21.34 1 usually ships 8-12 days
17 997-2011 Hose clamp $2.67 3 ships same day
18 202-4106 O-ring $5.50 1 usually ships 8-12 days
19 202-4200 Fill hose $66.56 1 usually ships 8-12 days
20 202-4232 Clip Call for price 2 usually ships 8-12 days
21 202-2189 Loop clamp rubber $5.50 1 usually ships 8-12 days
22 202-3175 P clamp $8.91 1 usually ships 1-5 days
23 999-0644 Bolt 1/4-20 x 1/2 hex head stainless steel $0.99 2 ships same day
24 999-0556 Bolt 5/16-18 x 3/4 hex head stainless steel $0.99 2 ships same day
25 999-0549 Washer 5/16 x 3/4 SAE flat stainless steel $0.99 2 ships same day
26 999-0998 Washer #10 flat stainless steel $0.99 4 ships same day
27 999-0632 Washer 1/4 split lock stainless steel $0.99 2 ships same day
28 999-0553 Washer 5/16 medium split lock stainless steel $0.99 2 ships same day
29 999-1350 Screw 10-32 x 1/2 inch phillips pan head stainless steel $0.99 4 ships same day
30 999-0870 Screw 8 x 3/4 pan head phillips stainless steel $0.99 6 ships same day
31 202-2592 Grommet $5.50 1 usually ships 8-12 days
32 202-4100 Barbed elbow 3/8 x 1/2 inch $7.81 1 usually ships 8-12 days
33 202-3440 Barbed elbow $23.32 2 usually ships 8-12 days
34 202-9496 Elbow, 1/4 inch Barb x 3/4 inch NPT Black $5.50 1 usually ships 8-12 days
35a 202-7047 TANK,SOLUTION/RECOVERY,GRANITE Standard tank $1,021.46 1 usually ships 8-12 days
35b 202-7048 TANK,SOLUTION/RECOVERY,RED Standard tank $776.60 1 usually ships 8-12 days
36 202-4234 Back cord tip $36.74 1 usually ships 8-12 days
