HERO Standard XL Tank Assembly

#PartDescriptionPriceReqNotesAvailability
1 202-3373 Drain hose cap $16.60 1 usually ships 3-11 days
2 202-3036 Strainer screen $38.00 1 usually ships 3-11 days
3 202-2025 Hosebarb $19.30 1 usually ships 3-11 days
4 202-6360 Curtain, Splash $16.30 1 usually ships 3-11 days
5 202-3582 Drain hose assembly $112.19 1 ships same day
6 202-2025 Hosebarb $19.30 3 usually ships 3-11 days
7 202-2118 Hosebarb $21.70 1 usually ships 3-11 days
8 202-3322 Tomcat decal $17.00 1 usually ships 1-5 days
9 202-3023 Squeegee vacuum hose $51.18 1 ships same day
10 202-4262 Bandeau to tank hose $38.00 1 usually ships 3-11 days
11 202-6941 Hose, Inner Tank $27.81 1 usually ships 3-11 days
12 202-6941 Hose, Inner Tank $27.81 1 usually ships 3-11 days
13 202-6956 Bracket, Tank Strap $34.20 1 usually ships 3-11 days
14 202-6974 Soundeading Kit $58.20 1 usually ships 3-11 days
15 202-7054 Lid,Screw-On,Tank $118.60 1 usually ships 3-11 days
16 202-0436 Tomcat front decal $19.40 1 usually ships 3-11 days
17 997-2011 Hose clamp $2.67 3 ships same day
18 202-4106 O-ring $5.00 1 usually ships 3-11 days
19 202-4200 Fill hose $60.51 1 usually ships 3-11 days
20 202-4232 Clip Call for price 2 usually ships 3-11 days
21 202-2189 Loop clamp rubber $5.00 1 usually ships 3-11 days
22 202-3175 P clamp $8.10 1 usually ships 1-5 days
23 999-0644 Bolt 1/4-20 x 1/2 hex head stainless steel $0.99 2 ships same day
24 999-0556 Bolt 5/16-18 x 3/4 hex head stainless steel $0.99 2 ships same day
25 999-0549 Washer 5/16 x 3/4 SAE flat stainless steel $0.99 2 ships same day
26 999-0998 Washer #10 flat stainless steel $0.99 4 ships same day
27 999-0632 Washer 1/4 split lock stainless steel $0.99 2 ships same day
28 999-0553 Washer 5/16 medium split lock stainless steel $0.99 2 ships same day
29 999-1350 Screw 10-32 x 1/2 inch phillips pan head stainless steel $0.99 4 ships same day
30 999-0870 Screw 8 x 3/4 pan head phillips stainless steel $0.99 6 ships same day
31 202-2592 Grommet $5.00 1 usually ships 3-11 days
32 202-4100 Barbed elbow 3/8 x 1/2 inch $7.10 1 usually ships 3-11 days
33 202-3440 Barbed elbow $21.20 2 usually ships 3-11 days
34 202-9496 Elbow, 1/4 inch Barb x 3/4 inch NPT Black $5.00 1 usually ships 3-11 days
35 202-7036 Tank,Solution/Recovery,Red,Complete XL tank $2,041.80 1 usually ships 3-11 days
36 202-4234 Back cord tip $33.40 1 usually ships 3-11 days
