HERO EDGE Lifting Bracket Assembly

#PartDescriptionPriceReqNotesAvailability
1 202-6396 Power Post, Black, 1/4 Terminal $7.80 usually ships 3-11 days
2 202-6397 Power Post, Red, 1/4 Terminal $8.10 usually ships 3-11 days
3 202-6400 Terminal Insulator, Black $9.80 usually ships 3-11 days
4 202-6401 Terminal Insulator, Red $9.80 usually ships 3-11 days
5 202-6440 Bracket, Deck Lifting, LH, Edge $78.80 usually ships 3-11 days
6 202-6441 Bracket, deck Lifting, RH, Edge $78.80 usually ships 3-11 days
7 202-6445 Arm, Lateral, Disk/Edge $226.05 usually ships 3-11 days
8 202-7656 Bushing,Flanged,5/16 inchIDx1/2 inchODx 1/4 inch, Hardened S $11.70 usually ships 3-11 days
9 202-0376 Hour meter $78.80 usually ships 3-11 days
10 202-5805 Body, Adjustable Lateral Arm $48.00 usually ships 3-11 days
11 999-1633 Clevis pin 3/8 x 3 1/2 $4.31 ships same day
12 202-2210 Washer 3/8 x 3/4 flat nylon $5.00 usually ships 3-11 days
13 202-2210 Washer 3/8 x 3/4 flat nylon $5.00 usually ships 3-11 days
14 202-1951 Sleeve $5.00 usually ships 3-11 days
15 999-0547 Bolt 5/16-18 x 1/2 hex head stainless steel $0.99 ships same day
16 999-0086 Nut 10-32 nylon insert lock zinc plated $0.99 ships same day
17 999-0423 Nut 5/16-18 nylon insert lock stainless steel $0.99 ships same day
18 999-0549 Washer 5/16 x 3/4 SAE flat stainless steel $0.99 ships same day
19 999-0553 Washer 5/16 medium split lock stainless steel $0.99 ships same day
20 999-1818 Screw 10-32 x 2 pan head phillips stainless steel $1.80 ships same day
21 999-9066 Bolt 5/16-18 x 1 carriage head stainless steel $1.34 ships same day
22 999-1370 Bolt 5/16-18 x 1 1/2 carriage head stainless steel $0.99 usually ships 1-5 days
23 202-2208 Compression spring $5.80 ships same day
24 202-2036 Cotter pin $7.50 usually ships 3-11 days
