HERO Squeegee Drag Link Assembly

#PartDescriptionPriceReqNotesAvailability
1 202-6314 Tool, 3 in 1 $7.10 1 usually ships 3-11 days
2 202-6417 Knob,Yellow $5.00 1 usually ships 3-11 days
3 202-6423 Plate, Squeegee Swing $67.30 1 usually ships 3-11 days
4 202-6430 Lift Cable,Squeegee,Black 31 inch $29.60 1 usually ships 3-11 days
5 202-6432 Body, Adjustable Lateral Arm Assy $78.40 1 usually ships 3-11 days
6 202-7052 Arm, Squeegee trail $51.60 1 usually ships 3-11 days
7 202-7055 Plate,Triangle,Squeegee $72.00 1 usually ships 3-11 days
8 202-9191 Washer,3/8 inchIDx1-1/2 inchOD,Nylon $5.00 1 usually ships 3-11 days
9 202-2210 Washer 3/8 x 3/4 flat nylon $5.00 5 usually ships 3-11 days
10 999-0298 Bolt 1/4-20 x 1 1/4 hex head stainless steel $0.99 2 ships same day
11 999-0424 Bolt 5/16-18 x 1 hex head stainless steel $0.99 2 ships same day
12 999-0086 Nut 10-32 nylon insert lock zinc plated $0.99 2 ships same day
13 999-0294 Nut 1/4-20 hex nylon lock type NE stainless steel $1.18 2 ships same day
14 999-0423 Nut 5/16-18 nylon insert lock stainless steel $0.99 3 ships same day
15 999-1482 Nut 3/8-16 nylon lock stainless steel $1.06 2 ships same day
16 999-0617 Washer 3/8 x 1 flat stainless steel $1.82 2 ships same day
17 999-0998 Washer #10 flat stainless steel $0.99 1 ships same day
18 999-1044 Screw 10-32 x 3/4 pan head phillips stainless steel $0.99 1 ships same day
19 999-1189 Screw 10-32 x 3/4 flat head phillips stainless steel $0.99 2 ships same day
20 999-0967 Bolt 5/16-18 x 3/4 carriage head stainless steel $2.16 1 ships same day
21 999-1150 Bolt 3/8-16 x 1 1/4 carriage head stainless steel $4.54 2 ships same day
22 999-0563 Washer 1/4 x 1/16 flat nylon $0.99 2 ships same day
23 202-4216 Spring $10.25 1 ships same day
24 202-6425 Arm,Squeegee Trail,Assembly $189.43 1 usually ships 3-11 days
