| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-5455
|
Wheel |
2 |
|
|
2 |
202-5463
|
Left side lock stay |
1 |
|
|
3 |
202-5464
|
Right side lock stay |
1 |
|
|
4 |
202-5465
|
Handle bar clamp |
1 |
|
|
5 |
202-5466
|
Handle bar |
1 |
|
|
6 |
202-5460
|
3/8-16 nylok flange |
2 |
|
|
7 |
202-5461
|
Washer 3/4 x 1 wave stainless steel |
2 |
|
|
8 |
202-2216
|
Shaft collar with set screw |
2 |
|
|
9 |
202-2210
|
Washer 3/8 x 3/4 flat nylon |
2 |
|
|
10 |
202-3194
|
Bolt 3/8-16 x 4 inch hex head stainless steel |
1 |
|
|
11 |
999-1868
|
Washer 3/8 x 1 1/4 flat stainless steel |
1 |
|
|
12 |
999-0346
|
Screw 5/16-18 x 1/4 set cup point socket alloy plain finish |
2 |
|
|
