| # | Part | Description | Price | Req | Notes | Availability |
|---|
0 |
202-7537
|
Main Motor,TR |
$1,020.47
|
1 |
(includes 1-20) |
usually ships 8-12 days |
1 |
202-2961
|
Terminal cover (black) |
$5.50
|
2 |
|
usually ships 1-5 days |
2 |
202-4435
|
Fan intake seal |
Call for price
|
1 |
|
usually ships 1-5 days |
3 |
202-5279
|
24V main broom motor |
$533.28
|
1 |
|
usually ships 8-12 days |
4 |
202-4436
|
Fan housing gasket |
Call for price
|
1 |
|
usually ships 1-5 days |
5 |
202-4437
|
Gan gasket bracket |
$28.88
|
1 |
|
usually ships 1-5 days |
6 |
202-4438
|
Blower face |
$40.34
|
1 |
|
usually ships 1-5 days |
7 |
202-4439
|
Fan housing |
$19.51
|
1 |
|
usually ships 1-5 days |
8 |
202-2691
|
Motor cradle |
$55.66
|
1 |
|
usually ships 8-12 days |
9 |
202-2695
|
Main drive pulley |
$52.58
|
1 |
|
usually ships 8-12 days |
10 |
202-2662
|
Blower wheel |
$233.75
|
1 |
|
usually ships 8-12 days |
11 |
202-2659
|
Motor support bracket |
$70.73
|
1 |
|
usually ships 1-5 days |
12 |
202-5105
|
1 inch rubber loop clamp |
$7.81
|
1 |
|
usually ships 1-5 days |
13 |
999-1840
|
Screw 5/16-18 x 5/16 knurled point socket set alloy steel |
$0.99
|
2 |
|
ships same day |
14 |
999-0668
|
Screw 5/16-18 x 3/8 socket knurled point set plain finish |
$0.99
|
1 |
|
ships same day |
15 |
202-1985
|
Screw 10 x 1/2 hex washer head |
$4.40
|
8 |
|
usually ships 1-5 days |
16 |
999-0556
|
Bolt 5/16-18 x 3/4 hex head stainless steel |
$0.99
|
2 |
|
ships same day |
17 |
999-0493
|
Bolt 3/8-16 x 3/4 hex head stainless steel |
$0.99
|
4 |
|
ships same day |
18 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
$0.99
|
2 |
|
ships same day |
19 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
$0.99
|
2 |
|
ships same day |
20 |
202-0140
|
Steering shaft key |
$5.50
|
2 |
|
usually ships 8-12 days |
