| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-1844
|
Screw 1/4-20 x 1/2 hex head stainless steel |
1 |
|
|
2 |
202-3603
|
250 squeegee drag plate |
1 |
|
|
3 |
202-1932
|
36V actuator |
1 |
|
|
4 |
202-1883
|
Main frame (OBSOLETE) |
1 |
|
|
5 |
999-9066
|
Bolt 5/16-18 x 1 carriage head stainless steel |
4 |
|
|
6 |
999-0262
|
Nut 1/2-13 nylon insert jam lock zinc plated |
1 |
|
|
7 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
1 |
|
|
