| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-1983
|
Tank lid (upper) (clear) |
|
Tank Lid Assembly |
|
1 |
202-1982
|
Tank lid gasket (upper) |
|
Tank Lid Assembly |
|
1 |
202-3246
|
Tank cover (stainless steel) |
|
Tank Lid Assembly |
|
1 |
202-3246
|
Tank cover (stainless steel) |
|
Tank Lid Assembly |
|
2 |
202-3063
|
Tank (red) |
|
Tank Assembly |
|
2 |
202-3064
|
Complete conversion kit to new tank-in-tank style (granite) |
|
Tank Assembly |
|
3 |
202-3059
|
Elbow barb |
|
Solution Hose Assembly |
|
4 |
202-3258
|
Reinforced tube |
|
Tank Assembly |
|
5 |
202-3057
|
Ball valve |
|
Solution Hose Assembly |
|
7 |
202-3234
|
Inline filter |
|
Solution Hose Assembly |
|
8 |
202-3230
|
Hose 1/2 x 10 inch (clear) |
|
Solution Hose Assembly |
|
9 |
202-3038
|
36V solenoid valve |
|
Solution Hose Assembly |
|
10 |
202-3101
|
Wire reinforced hose 1/2 x 14 inch |
|
Disk Scrub Deck Assembly |
|
11 |
202-0332
|
1/2 inch barbed tee |
|
Disk Scrub Deck Assembly |
|
12 |
202-3100
|
Tube (clear) |
|
Disk Scrub Deck Assembly |
|
12 |
202-0333
|
Elbow barb |
|
Disk Scrub Deck Assembly |
|
13 |
202-3260
|
Sight tube |
|
Tank Assembly |
|
