| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-3423
|
Solution fill lid stainless steel |
|
Tank Assembly - External |
|
1 |
202-3424
|
Solution fill lid gasket |
|
Tank Assembly - External |
|
1 |
202-3425
|
Screen |
|
Tank Assembly - External |
|
2 |
202-3428
|
Tank (granite) |
|
Tank Assembly - External |
|
2 |
202-3429
|
Tank assembly (red) |
|
Tank Assembly - External |
|
3 |
202-3440
|
Barbed elbow |
|
Tank Assembly - Internal |
|
4 |
202-3433
|
Hose 1/2 x 11 1/2 inch (clear) |
|
Tank Assembly - Internal |
|
6 |
202-3434
|
Hose 1/2 x 36 1/2 inch (clear) |
|
Tank Assembly - Internal |
|
7 |
202-2874
|
Filter screen |
|
Disk Scrub Deck Assembly |
|
7 |
999-0894
|
Screw 3/8-16 x 2 1/2 carriage head stainless steel |
|
Disk Scrub Deck Assembly |
|
8 |
202-3391
|
Wire reinforced hose 1/2 x 3 3/4 inch |
|
Disk Scrub Deck Assembly |
|
9a |
202-0674
|
Adjustable solution flow valve |
|
Disk Scrub Deck Assembly |
|
9b |
202-2291
|
Orange rubber stopper (OBSOLETE) |
|
|
|
9c |
202-2295
|
Diaphram |
|
|
|
10 |
202-3392
|
Wire reinforced hose 1/2 x 9 1/4 inch |
|
Disk Scrub Deck Assembly |
|
11 |
202-0332
|
1/2 inch barbed tee |
|
Disk Scrub Deck Assembly |
|
12 |
202-0333
|
Elbow barb |
|
Disk Scrub Deck Assembly |
|
12 |
202-3449
|
Wire reinforced hose 1/2 x 12 1/4 inch |
|
Disk Scrub Deck Assembly |
|
12 |
202-3450
|
Wire reinforced hose 1/2 x 16 1/4 inch |
|
Disk Scrub Deck Assembly |
|
13 |
202-3432
|
Hose 3/4 x 26 inch (clear) |
|
Tank Assembly - Internal |
|
