| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-5990
|
Hose, Tank to baffel |
1 |
|
|
2 |
202-9597
|
Clean air intake hose |
1 |
|
|
3 |
202-9598
|
Inner tank hose |
1 |
|
|
4 |
202-5995
|
Bracket, Tank Strap |
1 |
|
|
5 |
202-3036
|
Strainer screen |
1 |
|
|
6 |
202-6348
|
Soundeading Kit |
1 |
|
|
7 |
202-2025
|
Hosebarb |
1 |
|
|
8 |
202-6359
|
Curtain, Splash |
1 |
|
|
9 |
202-6371
|
Tube, Sight, 21/23 Gal |
1 |
|
|
10 |
202-6413
|
Gasket, Baffle Cap |
1 |
|
|
11 |
202-3582
|
Drain hose assembly |
1 |
|
|
12 |
202-2025
|
Hosebarb |
3 |
|
|
13 |
202-2118
|
Hosebarb |
1 |
|
|
14 |
202-3322
|
Tomcat decal |
1 |
|
|
15 |
202-3023
|
Squeegee vacuum hose |
1 |
|
|
16 |
202-0436
|
Tomcat front decal |
1 |
|
|
17 |
202-1487
|
Latch |
3 |
|
|
18 |
202-8038
|
4 inch Clear Access Port |
1 |
|
|
19 |
997-2011
|
Hose clamp |
3 |
|
|
20 |
997-2011
|
Hose clamp |
1 |
|
|
21 |
202-4200
|
Fill hose |
1 |
|
|
22 |
202-2189
|
Loop clamp rubber |
1 |
|
|
23 |
202-3175
|
P clamp |
1 |
|
|
24 |
999-0644
|
Bolt 1/4-20 x 1/2 hex head stainless steel |
2 |
|
|
25 |
999-0556
|
Bolt 5/16-18 x 3/4 hex head stainless steel |
2 |
|
|
26 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
2 |
|
|
27 |
999-0998
|
Washer #10 flat stainless steel |
5 |
|
|
28 |
999-0632
|
Washer 1/4 split lock stainless steel |
2 |
|
|
29 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
2 |
|
|
30 |
999-1290
|
Screw #14 x 1 truss head phillips stainless steel |
6 |
|
|
31 |
999-1350
|
Screw 10-32 x 1/2 inch phillips pan head stainless steel |
5 |
|
|
33 |
202-4100
|
Barbed elbow 3/8 x 1/2 inch |
1 |
|
|
34 |
202-3440
|
Barbed elbow |
2 |
|
|
35 |
202-9496
|
Elbow, 1/4 inch Barb x 3/4 inch NPT Black |
1 |
|
|
36 |
202-3239
|
Tee |
1 |
|
|
