| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-6069
|
Plate, Squeegee Swing |
1 |
|
|
2 |
202-6071
|
Arm, Squeegee Trail |
1 |
|
|
3 |
202-6432
|
Body, Adjustable Lateral Arm Assy |
1 |
|
|
4 |
202-7055
|
Plate,Triangle,Squeegee |
1 |
|
|
5 |
202-2210
|
Washer 3/8 x 3/4 flat nylon |
8 |
|
|
6 |
999-0424
|
Bolt 5/16-18 x 1 hex head stainless steel |
2 |
|
|
7 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
6 |
|
|
8 |
999-1482
|
Nut 3/8-16 nylon lock stainless steel |
2 |
|
|
9 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
2 |
|
|
10 |
999-0617
|
Washer 3/8 x 1 flat stainless steel |
2 |
|
|
11 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
2 |
|
|
12 |
999-1634
|
Bolt 5/16-18 x 1 1/2 hex head stainless steel |
2 |
|
|
13 |
999-1189
|
Screw 10-32 x 3/4 flat head phillips stainless steel |
2 |
|
|
14 |
999-0967
|
Bolt 5/16-18 x 3/4 carriage head stainless steel |
2 |
|
|
15 |
999-1348
|
Bolt 3/8-16 x 1 1/2 carriage head stainless steel |
2 |
|
|
16 |
202-2208
|
Compression spring |
2 |
|
|
