| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-0515
|
Solution flow control knob |
1 |
|
|
2 |
202-9896
|
Lever |
1 |
|
|
3 |
202-9897
|
Lever bracket |
1 |
|
|
4 |
202-9845
|
23-1/4 squeegee lift cable (black) |
1 |
|
|
5 |
202-9898
|
Stud 1/4-20 x 3 1/2 full |
4 |
|
|
6 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
4 |
|
|
7 |
999-0190
|
Nut 1/4-20 hex plain finish |
2 |
|
|
8 |
999-0294
|
Nut 1/4-20 hex nylon lock type NE stainless steel |
5 |
|
|
9 |
999-0211
|
Nut 5/16-18 hex nylon insert lock zinc plated |
1 |
|
|
10 |
999-9241
|
Washer 1 1/2 x 25/64 x 39/64 flat nylon |
2 |
|
|
11 |
999-9242
|
Screw 1/4-20 x 1 1/4 button head socket cap |
1 |
|
|
12 |
999-1507
|
Screw 5/16-18 x 1 button head socket stainless steel |
1 |
|
|
13 |
999-9243
|
Screw 5/16-18 x 1 flat head socket cap (3/16 hex drive) |
1 |
|
|
14 |
302-0218
|
Flanged bearing |
1 |
|
|
