| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-5376
|
1 1/2 inch elbow |
1 |
|
|
2 |
202-3582
|
Drain hose assembly |
1 |
|
|
3 |
203-7216
|
Vacuum hose |
1 |
|
|
4 |
202-9878
|
Tank gasket |
1 |
|
|
5 |
302-0210
|
Insulation |
1 |
|
|
6 |
302-0211
|
Gasket |
1 |
|
|
8 |
202-9882
|
Vac muffler |
1 |
|
|
9 |
202-9883
|
Vac cover |
1 |
|
|
10 |
302-0212
|
Ball chain lanyard |
1 |
|
|
11 |
202-9886
|
Ball float top |
1 |
|
|
12 |
202-9981
|
Vac screen |
1 |
|
|
13 |
202-9887
|
Push-on rubber gasket |
1 |
|
|
14 |
202-9888
|
Ball float gasket |
1 |
|
|
15 |
202-9889
|
4 inch lid gasket |
1 |
|
|
16 |
202-3914
|
Knob (red) |
2 |
|
|
17 |
202-9891
|
36V 3 stage vacuum motor |
1 |
|
|
18 |
202-9893
|
Baffle |
1 |
|
|
19 |
202-9894
|
Tank curtain |
1 |
|
|
20 |
202-9895
|
Strainer gasket |
1 |
|
|
21 |
202-7033
|
Vac Box Filter |
1 |
|
|
22 |
202-7090
|
Strainer,Screen 6 inch |
1 |
|
|
23 |
202-0232
|
Float shut-off ball |
1 |
|
|
25 |
202-8038
|
4 inch Clear Access Port |
1 |
|
|
26 |
302-0213
|
Screw #8-32 x 1.875 phillips pan head |
2 |
|
|
27 |
202-0898
|
Stud 1/4-20 x 5 threaded stainless steel |
3 |
|
|
28 |
202-2067
|
Nut 10-32 keps |
3 |
|
|
29 |
302-0124
|
Clamp |
2 |
|
|
30 |
999-0294
|
Nut 1/4-20 hex nylon lock type NE stainless steel |
3 |
|
|
31 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
3 |
|
|
32 |
999-0870
|
Screw 8 x 3/4 pan head phillips stainless steel |
6 |
|
|
33 |
202-1986
|
Washer 3/8 x 1-1/8 x 3/32 neoprene thread |
3 |
|
|
34a |
302-0214
|
Recovery tank (blue) |
1 |
|
|
34b |
302-0215
|
Recovery tank (green) |
1 |
|
|
34c |
302-0216
|
Recovery tank (granite) |
1 |
|
|
34d |
302-0217
|
Recovery tank (antimicrobial) |
1 |
|
|
N/S |
202-9880
|
Vacuum motor gasket |
1 |
|
|
N/S |
202-1487
|
Latch |
1 |
|
|
