| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-5405
|
3 inch wheel |
4 |
|
|
2 |
999-0963
|
Bolt 1/4-20 x 3/4 carriage head stainless steel |
12 |
|
|
3 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
12 |
|
|
4 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
4 |
|
|
5 |
999-0304
|
Nut 1/4-20 nylon lock jam stainless steel |
12 |
|
|
6 |
999-0278
|
Nut 5/16-18 nylon insert lock jam zinc plated |
4 |
|
|
7 |
999-1177
|
Screw 5/16-18 x 1 3/4 flat head socket stainless steel |
4 |
|
|
8a |
302-0179
|
26 inch shroud decal |
1 |
(26 inch) |
|
8b |
302-0180
|
28 inch shroud decal |
1 |
(28 inch) |
|
9a |
302-0181
|
26 inch shroud poly |
1 |
(26 inch) |
|
9b |
302-0182
|
28 inch shroud poly |
1 |
(28 inch) |
|
10a |
202-6355
|
Curtain, Shroud, 26 inch |
1 |
(26 inch) |
|
10b |
202-6356
|
Curtain, Shroud, 28 inch |
1 |
(28 inch) |
|
11a |
202-6357
|
Band, Shroud, 26 inch |
1 |
(26 inch) |
|
11b |
202-6358
|
Band, Shroud, 28 inch |
1 |
(28 inch) |
|
12a |
302-0183
|
26 inch shroud metal |
1 |
(26 inch) |
|
12b |
302-0184
|
28 inch shroud metal |
1 |
(28 inch) |
|
