| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
202-0168
|
Squeegee pitch adjusting knob |
$12.87
|
1 |
|
usually ships 8-12 days |
2 |
202-0169
|
Squeegee angle adjustment rod |
$98.45
|
1 |
|
usually ships 8-12 days |
3 |
202-1042
|
Squeegee Pivot Lug (Not Threaded) |
$59.95
|
1 |
|
usually ships 1-5 days |
4 |
202-0170
|
Squeegee pitch angle adjustment plate (OBSOLETE) |
$101.55
|
1 |
|
usually ships 8-12 days |
5 |
202-0171
|
Squeegee triangle plate |
$84.04
|
1 |
|
usually ships 1-5 days |
6 |
202-0172
|
Squeegee ball-joint |
$44.77
|
1 |
|
usually ships 8-12 days |
7a |
202-2305
|
Squeegee hitch |
$68.64
|
1 |
(before 04/2000) |
usually ships 1-5 days |
7b |
202-0173
|
Squeegee trail arm |
$241.12
|
1 |
(after 04/2000) |
usually ships 1-5 days |
8 |
202-1043
|
Squeegee Pivot Lug (Threaded) |
$59.95
|
1 |
|
usually ships 8-12 days |
9 |
202-0174
|
Squeegee guide wheels w/ collar and hardware (pkg of 2) |
$50.49
|
1 |
|
usually ships 8-12 days |
10 |
202-0008
|
Squeegee wheel with hardware (pkg of 2) |
$28.27
|
1 |
|
usually ships 8-12 days |
11 |
202-1876
|
45 inch squeegee assembly |
$620.54
|
1 |
|
usually ships 8-12 days |
12 |
202-0177
|
Squeegee wheel mounting bracket |
$162.47
|
2 |
|
usually ships 8-12 days |
13 |
202-0178
|
Squeegee pivot rod |
$119.68
|
1 |
|
usually ships 8-12 days |
14a |
202-0179
|
Squeegee lock knob (pkg of 2) |
$55.00
|
1 |
|
usually ships 1-5 days |
14b |
N/A
|
Not available |
Call for price
|
2 |
(belleville washer) |
usually ships 3-26 days |
14c |
N/A
|
Not available |
Call for price
|
2 |
(wingbolt) |
usually ships 3-26 days |
14d |
N/A
|
Not available |
Call for price
|
2 |
(buno-o ring) |
usually ships 3-26 days |
14e |
N/A
|
Not available |
Call for price
|
1 |
(new squeegee hold down system) |
usually ships 3-26 days |
14f |
202-1344
|
Squeegee body mounting pad |
$5.50
|
1 |
|
usually ships 1-5 days |
14g |
202-1044
|
Nut wing 3/8-16 nickel |
$13.75
|
2 |
|
ships same day |
14h |
202-9428
|
Stud,3/8-16x1-1/2 inch Full Thread,Stainless |
$5.50
|
2 |
|
usually ships 8-12 days |
15a |
202-0135
|
Squeegee swing limit cable with stop collars (OBSOLETE) |
$72.72
|
1 |
(before 04/2000) (old transmission) |
usually ships 8-12 days |
15b |
202-9959
|
Squeegee swing limit cable |
Call for price
|
1 |
(after 04/2000) (new transmission) |
usually ships 1-5 days |
15c |
202-9960
|
Squeegee swing limit cable mounting clamp |
Call for price
|
2 |
(new transmission units between 01/2000 and 03/2000 only) |
usually ships 1-5 days |
15d |
202-0182
|
Squeegee limitation cable mounting clamp |
$25.30
|
2 |
(new transmission units after 04/2000 only) |
usually ships 1-5 days |
16 |
202-1045
|
Squeegee Limitation Cable Eyebolt |
$34.10
|
1 |
|
usually ships 1-5 days |
N/S |
202-0164
|
Gum rubber kit |
$104.06
|
1 |
(includes 1 front blade, 2 rear blades, and 2 wheels) (gum rubber) |
usually ships 8-12 days |
N/S |
202-0165
|
Urethane kit |
$211.75
|
1 |
(includes 1 front blade, 2 rear blades, and 2 wheels) (neoprene) |
usually ships 1-5 days |
N/S |
202-0166
|
Front squeegee band 45 inch |
$136.62
|
1 |
|
usually ships 1-5 days |
N/S |
202-0167
|
Rear squeegee band 45 inch (OBSOLETE) |
$141.90
|
1 |
|
usually ships 1-5 days |
