| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
202-0397
|
Mainframe (OBSOLETE) |
$1,439.24
|
1 |
|
usually ships 1-5 days |
2 |
202-0422
|
Front apron (red) |
$243.32
|
1 |
|
usually ships 8-13 days |
3 |
202-8524
|
Pedestal,Steering |
$174.68
|
1 |
|
usually ships 8-13 days |
4a |
202-9935
|
Old style central command box |
Call for price
|
1 |
(before 03/99) (includes front only) |
usually ships 1-5 days |
4b |
202-9936
|
Old style central command rear plate |
Call for price
|
1 |
(before 03/99) (holds electrical) |
usually ships 1-5 days |
4c |
202-0357
|
Central command cover |
$230.56
|
1 |
|
usually ships 1-5 days |
4d |
202-8271
|
Control Panel,Front |
$416.90
|
1 |
|
usually ships 8-13 days |
4e |
202-0425
|
Wiring channel |
$132.88
|
1 |
|
usually ships 1-5 days |
5a |
202-8274
|
Battery Box |
$706.20
|
1 |
|
usually ships 8-13 days |
5b |
202-0083
|
Hinge (OBSOLETE) |
$14.30
|
1 |
|
usually ships 8-13 days |
6 |
202-9937
|
Battery box lid |
Call for price
|
1 |
|
usually ships 1-5 days |
7a |
202-0081
|
Seat with switch, cover, locking track and mounting |
$770.22
|
1 |
|
usually ships 8-13 days |
7b |
202-0082
|
Armrest kit (OBSOLETE) |
$115.98
|
1 |
|
usually ships 1-5 days |
8 |
202-8329
|
Tank,Solution,Polyethylene,Red |
$660.44
|
1 |
|
usually ships 8-13 days |
9 |
202-3379
|
Recovery tank (red) |
$906.07
|
1 |
|
usually ships 1-5 days |
10 |
202-0430
|
Nonskid floor plate |
$298.21
|
1 |
|
usually ships 1-5 days |
11 |
202-2022
|
Hood cable |
$28.49
|
1 |
|
usually ships 8-13 days |
12 |
202-0234
|
Tank lid and ring |
$155.76
|
1 |
|
usually ships 8-13 days |
16a |
202-0084
|
Battery tray black plastic (OBSOLETE) |
$27.72
|
1 |
|
usually ships 1-5 days |
16b |
202-0078
|
Plywood battery underlayment |
$32.67
|
1 |
|
usually ships 1-5 days |
19 |
202-9934
|
Model 40 decal |
$5.28
|
2 |
|
usually ships 1-5 days |
21 |
202-0436
|
Tomcat front decal |
$22.22
|
1 |
|
usually ships 8-13 days |
22a |
202-0242
|
Tank tie down strap complete for poly tanks |
$45.52
|
1 |
|
usually ships 1-5 days |
22b |
202-8336
|
Strap,Tank Tie Down |
$99.99
|
1 |
(optional) |
usually ships 8-13 days |
22c |
202-0244
|
Tank tie-down strap belt attachment rear |
$20.90
|
1 |
|
usually ships 1-5 days |
22d |
202-0242
|
Tank tie down strap complete for poly tanks |
$45.52
|
1 |
|
usually ships 1-5 days |
22e |
202-0243
|
Tank tie down strap hook |
$19.80
|
1 |
|
usually ships 1-5 days |
N/S |
202-0417
|
Front splash curtain holddown bar set |
$229.79
|
1 |
|
usually ships 1-5 days |
N/S |
202-0434
|
Battery tray drain hose |
$5.50
|
1 |
|
usually ships 1-5 days |
