| # | Part | Description |
Req | Notes | Availability |
|---|
2 |
202-3622
|
Power keychain |
1 |
|
|
3 |
202-3622
|
Power keychain |
1 |
|
|
5 |
202-4159
|
40amp brush pressure gauge |
1 |
|
|
6 |
202-4160
|
40amp resettable fuse |
2 |
|
|
7 |
202-5609
|
36V battery/hour meter |
1 |
|
|
8 |
202-3631
|
Rocker switch (amber) |
1 |
|
|
9 |
202-3632
|
Rocker switch (green) |
1 |
|
|
10 |
202-3633
|
Rocker switch (blue) |
1 |
|
|
11 |
202-0832
|
Full recovery indicator (red) |
2 |
|
|
12 |
202-2300
|
Key switch with key entry (red) and ring (black) |
1 |
|
|
13 |
202-7203
|
Light,24V,Green,Bulb Style |
1 |
|
|
14 |
991-1634
|
Key (pkg of 2) |
2 |
|
|
15 |
202-7204
|
Light,24V,Yellow,Bulb Style |
2 |
|
|
18 |
202-3340
|
Toggle switch |
1 |
|
|
19 |
202-1992
|
Toggle switch |
2 |
|
|
20 |
202-0097
|
Toggle switch |
1 |
|
|
21 |
202-2499
|
15amp fuse |
6 |
|
|
22 |
202-0341
|
6 Amp circuit breaker |
1 |
|
|
23 |
202-8199
|
Breaker, 5a |
2 |
|
|
24 |
202-0369
|
2 position rocker switch |
1 |
|
|
30 |
202-3817
|
Central command top |
1 |
|
|
32 |
202-0822
|
2amp fuse |
1 |
|
|
33 |
202-3625
|
Dual USB ports |
1 |
|
|
39 |
202-1864
|
Toggle switch protective boot (red) |
1 |
|
|
40 |
202-1977
|
Toggle switch protective boot (yellow) |
1 |
|
|
41 |
202-1355
|
Toggle switch protective boot (black) |
1 |
|
|
42 |
202-3465
|
Toggle switch protective boot (orange) |
1 |
|
|
43 |
999-0435
|
Screw 1/4-20 x 5/8 socket head alloy plain finish |
4 |
|
|
57 |
999-1480
|
Screw 1/4-20 x 5/8 button head socket cap stainless steel |
3 |
|
|
