| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-6346
|
Rod, Drain Saver Basket |
2 |
|
|
2 |
202-4326
|
Top stainer with gasket |
1 |
|
|
3 |
202-6413
|
Gasket, Baffle Cap |
1 |
|
|
4 |
202-6414
|
Gasket, Ball Float |
1 |
|
|
5 |
202-7033
|
Vac Box Filter |
1 |
|
|
6 |
202-7065
|
Drain Saver Basket Complete |
1 |
|
|
7 |
202-7090
|
Strainer,Screen 6 inch |
1 |
|
|
8 |
202-0232
|
Float shut-off ball |
1 |
|
|
9 |
202-0230
|
Strainer gasket |
1 |
|
|
10 |
202-8038
|
4 inch Clear Access Port |
1 |
|
|
11 |
202-9805
|
Vac screen box |
1 |
|
|
12 |
202-9806
|
Drain saver basket flap |
1 |
|
|
13 |
202-9807
|
Baffle |
1 |
|
|
14 |
202-9808
|
Baffle bracket |
1 |
|
|
15 |
999-0086
|
Nut 10-32 nylon insert lock zinc plated |
5 |
|
|
17 |
202-2067
|
Nut 10-32 keps |
2 |
|
|
18 |
202-3316
|
Washer flat stainless steel |
3 |
|
|
19 |
999-1631
|
Screw 10-32 x 1 1/2 pan head phillips stainless steel |
2 |
|
|
20 |
999-1009
|
Screw 10-32 x 1/2 flat head phillips stainless steel |
3 |
|
|
21 |
999-1189
|
Screw 10-32 x 3/4 flat head phillips stainless steel |
2 |
|
|
22 |
999-1345
|
Screw 1/4-20 x 1 flat head phillips stainless steel |
4 |
|
|
23 |
999-1919
|
#8-15 x 1/2 phillips pan head sheet metal SS |
6 |
|
|
24 |
202-9537
|
O-Ring,3-1/2ID x 3-5/8 OD x 1/16 inch |
1 |
|
|
N/S |
999-0294
|
Nut 1/4-20 hex nylon lock type NE stainless steel |
4 |
|
|
