Cylindrical Wiper Assembly

#PartDescription ReqNotesAvailability
1 202-3137 Hinge 1
2 202-5123 Wiper band 1
3 202-3127 4 inch chain (6 inch no longer available) 1
4 202-9647 Vertical arm shroud 1
5 202-9649 Side shroud 1
6 202-3734 Adjustable wiper arm 1
7 202-3735 Adjustable rod end 1
8 999-1633 Clevis pin 3/8 x 3 1/2 1
9 999-1508 Bolt 10-32 x 5/8 round carriage head stainless steel 1
10 999-1457 Bolt 5/16-18 x 5/8 round head carriage stainless steel 2
11 999-0297 Bolt 1/4-20 x 1 hex head stainless steel 1
12 202-9341 Screw,Hex Cap,5/16-18x2 inch Stainless 1
13 999-0609 Nut 1/4-20 hex stainless steel 1
14 999-0086 Nut 10-32 nylon insert lock zinc plated 1
15 202-2067 Nut 10-32 keps 1
16 202-3316 Washer flat stainless steel 1
17 999-0549 Washer 5/16 x 3/4 SAE flat stainless steel 6
18 999-0617 Washer 3/8 x 1 flat stainless steel 2
20 202-2831 Screw 5/16-18 x 3/4 flat head socket stainless steel 1
21 202-2343 Screw 5/16-18 x 1 1/4 flat head stainless steel 1
22 999-0963 Bolt 1/4-20 x 3/4 carriage head stainless steel 5
23 999-1401 Bolt 1/4-20 x 1 carriage head stainless steel 1
24 202-2208 Compression spring 1
25 999-0304 Nut 1/4-20 nylon lock jam stainless steel 9
26 999-1019 Nut 5/16-18 hex jam stainless steel 5
27 202-2036 Cotter pin 1
28 202-3129 Cotter pin 1
29a 202-9726 Left hand horizontal arm shroud 1 (left hand)
29b 202-9725 Right hand horizontal arm shroud 1 (right hand)
30a 202-3019 Shroud curtain linatex (red) 1 (linatex)
30b 202-3381 Shroud curtain gum rubber (tan) 1 (gum rubber)
30c 202-6613 Curtain,Wiper,Urethane 1 (urethane)
31 202-9727 Left hand horizontal arm shroud complete 1
32 202-9724 Right hand horizontal arm shroud complete 1
N/S 999-1345 Screw 1/4-20 x 1 flat head phillips stainless steel 1
