| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-6592
|
Guard,Front,LH |
1 |
|
|
2 |
202-6593
|
Guard,Front,RH |
1 |
|
|
3 |
202-6615
|
Band,Curtain |
1 |
|
|
4 |
202-9708
|
Cylindrical curtain |
1 |
|
|
5 |
999-0294
|
Nut 1/4-20 hex nylon lock type NE stainless steel |
4 |
|
|
6 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
8 |
|
|
7 |
999-0963
|
Bolt 1/4-20 x 3/4 carriage head stainless steel |
4 |
|
|
8 |
999-9066
|
Bolt 5/16-18 x 1 carriage head stainless steel |
8 |
|
|
