| # | Part | Description |
Req | Notes | Availability |
|---|
3 |
202-0756
|
Guide roller |
8 |
|
|
4 |
202-2754
|
Adjustment knob |
2 |
|
|
5 |
202-5560
|
Lower roller bracket |
2 |
|
|
6 |
202-5546
|
9-60V LED head light |
2 |
|
|
8 |
202-5284
|
Nut 1/4-20 hex crimp long |
8 |
|
|
9 |
999-1829
|
Screw 5/16-18 x 2 1/2 socket head stainless steel |
2 |
|
|
10 |
202-3538
|
P clamp |
1 |
|
|
11 |
999-1209
|
Bolt 5/8-11 x 4 hex head zinc plated |
2 |
|
|
12 |
999-1209
|
Bolt 5/8-11 x 4 hex head zinc plated |
2 |
|
|
13 |
999-6723
|
Bolt 5/8-11 x 7 hex head grade 5 zinc plated |
2 |
|
|
14 |
999-0069
|
Nut 5/16-18 hex |
2 |
|
|
16 |
999-0968
|
Nut 5/8-11 nylon insert jam lock zinc plated |
2 |
|
|
17 |
999-0334
|
Bolt 1/4-20 x 3/4 inch hex head stainless steel |
5 |
|
|
18 |
999-0593
|
Nut 5/16-18 hex stainless steel |
2 |
|
|
19 |
999-0294
|
Nut 1/4-20 hex nylon lock type NE stainless steel |
6 |
|
|
20 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
5 |
|
|
21 |
999-0704
|
Nut 5/8-11 nylon insert lock stainless steel |
4 |
|
|
22 |
999-1466
|
Nut 1/4-20 lock with external toothed lockwasher SS |
1 |
|
|
23 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
5 |
|
|
24 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
4 |
|
|
25 |
999-0632
|
Washer 1/4 split lock stainless steel |
5 |
|
|
26 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
6 |
|
|
27 |
999-0963
|
Bolt 1/4-20 x 3/4 carriage head stainless steel |
5 |
|
|
28 |
999-1401
|
Bolt 1/4-20 x 1 carriage head stainless steel |
2 |
|
|
29 |
999-9066
|
Bolt 5/16-18 x 1 carriage head stainless steel |
10 |
|
|
30 |
202-5562
|
Bolt 15/16 inch plastic hex cap |
2 |
|
|
31a |
202-0976
|
20 inch roller bracket |
2 |
(34 and 36 inch disk) (33 inch cylindrical) |
|
31b |
202-7154
|
Bracket Roller |
2 |
(37 inch cylindrical) |
|
N/S |
202-5316
|
Lifting bracket |
1 |
|
|
N/S |
202-9706
|
Side broom pivot |
1 |
|
|
N/S |
202-3175
|
P clamp |
1 |
|
|
