Pilot V2.0 Solution and Sprayjet Assembly

#PartDescriptionPriceReqNotesAvailability
1 202-0097 Toggle switch $15.73 1 usually ships 3-11 days
2 202-2368 36V water jet pump $933.46 1 usually ships 3-11 days
3 202-0332 1/2 inch barbed tee $5.50 1 ships same day
4 202-1031 Clamp $6.71 1 usually ships 3-11 days
5 202-5569 Rear sight tube $38.06 1 usually ships 3-11 days
6 202-5571 3/4 inch plastic barb tee $5.50 1 usually ships 1-5 days
7 202-0884 Barbed elbow $4.95 1 usually ships 3-11 days
8 202-5145 Coupling $5.50 1 usually ships 1-5 days
9 202-0680 Hose clamp $5.50 1 usually ships 3-11 days
10 202-1865 Toggle switch protective boot (blue) $13.20 1 usually ships 3-11 days
11 999-1471 Screw #10-21 x 1 flat head phillips stainless steel $0.99 1 ships same day
12 202-4003 Grommet $5.50 2 usually ships 1-5 days
13 202-5106 Reinforced hose 1/2 x 60 inch $33.22 1 usually ships 1-5 days
14 202-5106 Reinforced hose 1/2 x 60 inch $33.22 1 usually ships 1-5 days
15 202-5106 Reinforced hose 1/2 x 60 inch $33.22 1 usually ships 1-5 days
16 202-3776 Reinforced solution hose 3/4 inch x 5 foot Call for price 1 usually ships 3-11 days
17 202-3776 Reinforced solution hose 3/4 inch x 5 foot Call for price 1 usually ships 3-11 days
