| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-3269
|
Solution tank (stainless steel) |
1 |
|
|
2 |
202-1487
|
Latch |
1 |
|
|
3 |
202-0333
|
Elbow barb |
1 |
|
|
4 |
999-0330
|
Nut 1/2-13 acorn brass |
1 |
|
|
5 |
202-2145
|
Washer 3/4 rubber |
1 |
|
|
6 |
999-0559
|
Washer 1/2 x 1/4 flat stainless steel |
1 |
|
|
7 |
202-3270
|
Vertical float valve switch w/ washer |
1 |
|
|
8 |
999-1506
|
Screw M10-1.5 x 22mm socket set |
1 |
|
|
9 |
202-3272
|
Bulkhead fitting |
1 |
|
|
10 |
202-2385
|
67 inch push-on rubber gasket |
1 |
|
|
11 |
202-0403
|
Hinge |
1 |
|
|
12 |
202-3273
|
Tank cover |
1 |
|
|
13 |
202-3274
|
Bracket |
1 |
|
|
14 |
999-0963
|
Bolt 1/4-20 x 3/4 carriage head stainless steel |
4 |
|
|
15 |
N/A
|
Not available |
1 |
(Hose 1/2 x 4 inch) |
|
16 |
999-0294
|
Nut 1/4-20 hex nylon lock type NE stainless steel |
4 |
|
|
17 |
999-1484
|
Bolt 1/4-20 x 5/8 round head carriage stainless steel |
3 |
|
|
19 |
202-3275
|
Rubber bumper |
3 |
|
|
20 |
999-1044
|
Screw 10-32 x 3/4 pan head phillips stainless steel |
3 |
|
|
21 |
999-0086
|
Nut 10-32 nylon insert lock zinc plated |
3 |
|
|
22 |
999-0357
|
Nut 8-32 nylon insert lock stainless steel |
2 |
|
|
23 |
999-0358
|
Screw 8-32 x 5/8 pan head phillips stainless steel |
2 |
|
|
24 |
999-0429
|
Nut 1/4-20 acorn nickel plated |
3 |
|
|
25 |
999-0632
|
Washer 1/4 split lock stainless steel |
3 |
|
|
26 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
3 |
|
|
