| # | Part | Description | Price | Req | Notes | Availability |
|---|
0a |
202-3204
|
34 inch squeegee assembly |
$1,451.56
|
1 |
(34 inch) (includes 1-5, 6a, 7a, 8a, 9a, 10a, 11-30, 31a and 32a) |
usually ships 8-13 days |
0b |
202-3212
|
53 inch squeegee assembly |
$1,490.39
|
1 |
(40 inch) (includes 1-5, 6b, 7b, 8b, 9b, 10b, 11-30, 31c and 32c) |
usually ships 8-13 days |
1 |
202-2098
|
4 inch wheel (gray) |
$43.23
|
4 |
|
usually ships 8-13 days |
2 |
202-0702
|
Spacer |
$5.50
|
6 |
|
usually ships 8-13 days |
3 |
202-1999
|
Star knob |
$45.65
|
4 |
|
usually ships 8-13 days |
4 |
202-3182
|
Bracket |
$44.55
|
2 |
|
usually ships 1-5 days |
5 |
202-2898
|
Latch |
$45.76
|
1 |
|
usually ships 8-13 days |
6a |
202-3183
|
34 inch right side rear squeegee band |
$128.26
|
1 |
(34 inch) |
usually ships 1-5 days |
6b |
202-3205
|
40 and 45 inch right side rear squeegee band |
$91.19
|
1 |
(40 inch) |
usually ships 8-13 days |
7a |
202-3184
|
34 inch left side rear squeegee band |
$129.91
|
1 |
(34 inch) |
usually ships 1-5 days |
7b |
202-3206
|
40 inch left side rear squeegee band |
$120.67
|
1 |
(40 inch) |
usually ships 1-5 days |
8a |
202-3185
|
34 inch front squeegee band |
$172.81
|
1 |
(34 inch) |
usually ships 1-5 days |
8b |
202-3207
|
40 inch front squeegee band |
$77.88
|
1 |
(40 inch) |
usually ships 8-13 days |
9a |
202-3186
|
34 inch bottom weldment plate |
$53.57
|
2 |
(34 inch) |
usually ships 1-5 days |
9b |
202-3209
|
40 inch bottom weldment plate |
$93.83
|
1 |
(40 inch) |
usually ships 8-13 days |
10a |
202-3187
|
34 inch squeegee weldment |
$587.84
|
1 |
(34 inch) |
usually ships 1-5 days |
10b |
202-3208
|
40 inch squeegee weldment |
$506.77
|
1 |
(40 inch) |
usually ships 1-5 days |
11 |
202-3188
|
Caster bracket |
$103.29
|
2 |
|
usually ships 8-13 days |
12 |
202-3189
|
Spacer |
$19.14
|
4 |
|
usually ships 1-5 days |
13 |
202-0711
|
Clamping knob (pkg of 2) |
$17.16
|
6 |
|
ships same day |
14 |
999-1269
|
Nut 10-32 nylon insert jam stainless steel |
$0.99
|
2 |
|
usually ships 16-20 days |
15 |
202-3191
|
Screw 1/4-20 x 3 1/4 socket head stainless steel |
$9.02
|
2 |
|
usually ships 8-13 days |
16 |
999-1273
|
Screw 3/8-16 x 3 1/2 button head socket stainless steel |
$15.29
|
4 |
|
usually ships 8-13 days |
17 |
999-0304
|
Nut 1/4-20 nylon lock jam stainless steel |
$0.99
|
6 |
|
ships same day |
18 |
999-9071
|
Nut 3/8-16 nylon insert jam lock stainless steel |
$1.52
|
4 |
|
ships same day |
19 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.99
|
6 |
|
ships same day |
20a |
999-0632
|
Washer 1/4 split lock stainless steel |
$0.99
|
6 |
(34 inch) |
ships same day |
20b |
999-0429
|
Nut 1/4-20 acorn nickel plated |
$0.99
|
2 |
(40 inch) |
ships same day |
21 |
999-0659
|
Washer 3/8 medium split lock stainless steel |
$0.39
|
4 |
|
ships same day |
22 |
202-3193
|
Bolt 3/8-16 x 3 inch hex head stainless steel |
$5.50
|
2 |
|
usually ships 8-13 days |
23 |
202-3194
|
Bolt 3/8-16 x 4 inch hex head stainless steel |
$7.81
|
2 |
|
usually ships 1-5 days |
24a |
999-1345
|
Screw 1/4-20 x 1 flat head phillips stainless steel |
$0.99
|
4 |
(34 inch) |
ships same day |
24b |
999-1501
|
Screw 1/4-20 x 3 1/2 flat head phillips stainless steel |
$2.05
|
2 |
(40 inch) |
usually ships 1-5 days |
25a |
202-3195
|
Screw 1/4-20 x 2-1/2 inch socket stainless steel |
$5.50
|
2 |
(34 inch) |
usually ships 8-13 days |
25b |
999-1447
|
Screw 1/4-20 x 1 3/4 flat socket head stainless steel |
$2.22
|
2 |
(40 inch) |
ships same day |
26 |
202-3196
|
Screw 1/4-20 x 3 inch socket stainless steel |
$5.50
|
2 |
|
usually ships 8-13 days |
27 |
202-3197
|
Screw 10-32 x 3/8 inch button head socket stainless steel |
$5.50
|
2 |
|
usually ships 8-13 days |
28 |
202-3198
|
Screw 1/4-20 x 2-1/2 inch hex head stainless steel |
$5.50
|
6 |
|
usually ships 8-13 days |
29 |
202-3199
|
Spacer |
$10.18
|
2 |
|
usually ships 1-5 days |
30 |
999-0324
|
Nut 3/8-16 nylon insert lock jam zinc plated |
$0.99
|
4 |
|
ships same day |
31a |
202-3200
|
Squeegee blade 34 inch linatex front |
$128.92
|
1 |
(34 inch) |
usually ships 8-13 days |
31b |
202-3201
|
Squeegee blade 34 inch gum rubber front |
$71.17
|
1 |
(34 inch) |
usually ships 1-5 days |
31c |
202-2937
|
Squeegee blade 40 inch linatex front |
$114.07
|
1 |
(40 inch) |
usually ships 8-13 days |
31d |
202-2956
|
Squeegee blade 40 inch gum rubber front |
$90.75
|
1 |
(40 inch) |
usually ships 8-13 days |
32a |
202-3202
|
Squeegee blade 34 inch linatex rear |
$94.38
|
1 |
(34 inch) |
usually ships 8-13 days |
32b |
202-3203
|
Squeegee blade 34 inch gum rubber rear (OBSOLETE) |
$77.88
|
1 |
(34 inch) |
usually ships 8-13 days |
32c |
202-2938
|
Squeegee blade 40 inch linatex rear (red) |
$127.60
|
1 |
(40 inch) |
usually ships 8-13 days |
32d |
202-2957
|
Squeegee blade 40 inch gum rubber rear |
$109.23
|
1 |
(40 inch) |
usually ships 8-13 days |
