| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-1008
|
Barbed elbow |
2 |
|
|
2 |
202-3485
|
Wire reinforced clear hose 1/2 x 12 1/4 inch |
1 |
|
|
3 |
202-3486
|
Wire reinforced clear hose 1/2 x 13 1/2 inch |
1 |
|
|
4 |
202-3487
|
Wire reinforced clear hose 1/2 x 24 inch |
1 |
|
|
5 |
202-0104
|
18 foot rubber hose (blue) |
1 |
|
|
6 |
202-0101
|
60 PSI water jet pump |
1 |
|
|
7 |
202-0103
|
Spray nozzle |
1 |
|
|
8 |
999-1470
|
Rubber washer |
1 |
|
|
9 |
202-2066
|
Hose clamp |
2 |
|
|
10 |
999-0086
|
Nut 10-32 nylon insert lock zinc plated |
4 |
|
|
11 |
202-2067
|
Nut 10-32 keps |
4 |
|
|
12 |
999-1485
|
Washer #10 flat large stainless steel |
4 |
|
|
13 |
999-1366
|
Screw 8-32 x 3/8 round head phillips stainless steel |
4 |
|
|
14 |
202-3239
|
Tee |
1 |
|
|
