| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
202-0976
|
20 inch roller bracket |
$36.52
|
1 |
|
usually ships 3-11 days |
2 |
202-0756
|
Guide roller |
$28.16
|
2 |
|
usually ships 3-11 days |
3 |
202-3489
|
Inner jaw hinge |
$28.82
|
1 |
|
usually ships 3-11 days |
4 |
202-3490
|
Jaw lock |
$43.89
|
1 |
|
usually ships 3-11 days |
5 |
202-1487
|
Latch |
$25.19
|
1 |
|
usually ships 3-11 days |
6 |
999-6723
|
Bolt 5/8-11 x 7 hex head grade 5 zinc plated |
$12.54
|
1 |
|
ships same day |
7 |
999-0968
|
Nut 5/8-11 nylon insert jam lock zinc plated |
$2.27
|
1 |
|
ships same day |
8 |
999-0593
|
Nut 5/16-18 hex stainless steel |
$0.99
|
2 |
|
ships same day |
9 |
999-0357
|
Nut 8-32 nylon insert lock stainless steel |
$0.99
|
2 |
|
ships same day |
10 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
$0.99
|
5 |
|
ships same day |
11 |
999-1466
|
Nut 1/4-20 lock with external toothed lockwasher SS |
$0.99
|
11 |
|
ships same day |
12 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.99
|
2 |
|
ships same day |
13 |
999-0916
|
Screw 8-32 x 1/2 pan head phillips stainless steel |
$0.99
|
2 |
|
ships same day |
14 |
999-0338
|
Screw 1/4-20 x 1/2 socket head shoulder |
$8.75
|
1 |
|
ships same day |
15 |
999-1484
|
Bolt 1/4-20 x 5/8 round head carriage stainless steel |
$0.99
|
9 |
|
ships same day |
16 |
999-0963
|
Bolt 1/4-20 x 3/4 carriage head stainless steel |
$1.50
|
4 |
|
ships same day |
17 |
999-9066
|
Bolt 5/16-18 x 1 carriage head stainless steel |
$1.34
|
3 |
|
ships same day |
18 |
999-6724
|
U bolt 5/16-18 x 1 1/4 stainless steel |
$12.21
|
1 |
|
ships same day |
19 |
202-5182
|
Clevis pin |
$5.50
|
1 |
|
usually ships 11-24 days |
20 |
999-0304
|
Nut 1/4-20 nylon lock jam stainless steel |
$0.99
|
3 |
|
ships same day |
24 |
202-0902
|
Lanyard |
$6.38
|
1 |
(left jaw) |
ships same day |
25 |
202-1487
|
Latch |
$25.19
|
1 |
(left jaw) |
usually ships 3-11 days |
26 |
999-0357
|
Nut 8-32 nylon insert lock stainless steel |
$0.99
|
1 |
(left jaw) |
ships same day |
27 |
999-0086
|
Nut 10-32 nylon insert lock zinc plated |
$0.99
|
1 |
(left jaw) |
ships same day |
28 |
999-0916
|
Screw 8-32 x 1/2 pan head phillips stainless steel |
$0.99
|
1 |
(left jaw) |
ships same day |
29 |
999-1350
|
Screw 10-32 x 1/2 inch phillips pan head stainless steel |
$0.99
|
1 |
(left jaw) |
ships same day |
30 |
202-3501
|
Ring pin |
$16.17
|
1 |
(left jaw) |
usually ships 3-11 days |
31a |
202-3491
|
26 inch right side jaw |
$481.36
|
1 |
|
usually ships 3-11 days |
31b |
202-3492
|
30 inch right side jaw |
$501.71
|
1 |
|
usually ships 1-5 days |
31c |
202-3493
|
34 inch right side jaw |
$329.12
|
1 |
|
usually ships 3-11 days |
32a |
202-3494
|
26 inch curtain blade |
$56.98
|
2 |
|
usually ships 3-11 days |
32b |
202-3393
|
30 inch curtain blade |
$61.49
|
2 |
|
usually ships 3-11 days |
32c |
202-3369
|
34 inch curtain blade |
$59.51
|
2 |
|
usually ships 3-11 days |
33a |
202-3495
|
26 inch curtain band |
$67.87
|
2 |
|
usually ships 3-11 days |
33b |
202-3496
|
30 inch curtain band |
$41.14
|
2 |
|
usually ships 1-5 days |
33c |
202-3497
|
34 inch curtain band |
$43.01
|
2 |
|
usually ships 3-11 days |
34a |
202-3498
|
26 inch left side jaw |
$415.36
|
1 |
|
usually ships 3-11 days |
34b |
202-3499
|
30 inch left side jaw |
$501.71
|
1 |
|
usually ships 1-5 days |
34c |
202-3500
|
34 inch left side jaw |
$329.12
|
1 |
|
usually ships 3-11 days |
