| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
202-4115
|
17 inch scrub deck |
$305.58
|
1 |
|
usually ships 1-5 days |
2 |
202-4116
|
Hose 1/2 x 2 3/4 inch (clear) |
$4.68
|
1 |
|
usually ships 3-11 days |
3 |
202-4117
|
Hose 1/2 x 14 inch (clear) |
$11.88
|
1 |
|
usually ships 3-11 days |
4 |
202-4118
|
Ball valve with fitting |
$49.39
|
1 |
|
usually ships 3-11 days |
5 |
202-4119
|
Lateral arm |
$152.46
|
1 |
|
usually ships 3-11 days |
6 |
202-2078
|
Deck Wheel Pivot Bracket |
$46.20
|
1 |
|
usually ships 1-5 days |
7 |
202-2079
|
Deck wheel pivot support |
$19.36
|
1 |
|
usually ships 1-5 days |
8 |
202-2080
|
4.0 inch Wheel |
$62.15
|
1 |
|
usually ships 3-11 days |
9 |
202-2086
|
Adjustable Solution Flow Valve |
$104.28
|
1 |
|
usually ships 3-11 days |
10 |
202-0702
|
Spacer |
$5.50
|
2 |
|
usually ships 3-11 days |
11 |
202-0330
|
Metal brush driver |
$147.95
|
1 |
|
usually ships 3-11 days |
12 |
202-5405
|
3 inch wheel |
$8.80
|
2 |
|
usually ships 3-11 days |
13 |
202-1239
|
Flanged bearing |
$5.50
|
10 |
|
usually ships 3-11 days |
14 |
202-0809
|
Brass star knob |
$41.14
|
3 |
|
usually ships 3-11 days |
15 |
202-0324
|
Scrub head lateral arm |
$26.73
|
2 |
|
usually ships 1-5 days |
16 |
202-0331
|
Brush driver key (pkg of 2) |
$9.90
|
1 |
|
ships same day |
17 |
202-0333
|
Elbow barb |
$5.50
|
1 |
|
ships same day |
18 |
999-0894
|
Screw 3/8-16 x 2 1/2 carriage head stainless steel |
$3.61
|
1 |
|
ships same day |
19 |
202-0480
|
24V 3/4HP brush motor |
$536.77
|
1 |
|
usually ships 3-11 days |
20 |
999-1151
|
Nut 3/8-24 nylon insert jam lock stainless steel |
$2.02
|
3 |
|
ships same day |
21 |
999-0330
|
Nut 1/2-13 acorn brass |
$5.72
|
2 |
|
ships same day |
22 |
202-2945
|
Spring |
$5.50
|
1 |
|
usually ships 3-11 days |
23 |
202-5193
|
Clevis pin 3/8 x 2 |
$5.50
|
1 |
|
usually ships 3-11 days |
24 |
999-0424
|
Bolt 5/16-18 x 1 hex head stainless steel |
$0.99
|
1 |
|
ships same day |
25 |
999-0562
|
Bolt 3/8-16 x 1 hex head stainless steel |
$1.50
|
4 |
|
ships same day |
26 |
999-9076
|
Screw 3/8 -16 x 2 1/4 hex head stainless steel |
$1.38
|
1 |
|
ships same day |
27 |
999-1568
|
Screw 3/8-24 x 2 hex head stainless steel |
$3.64
|
2 |
|
usually ships 1-5 days |
28 |
999-0593
|
Nut 5/16-18 hex stainless steel |
$0.99
|
2 |
|
ships same day |
29 |
999-0651
|
Nut 1/4-28 hex stainless steel |
$0.99
|
1 |
|
ships same day |
30 |
999-0294
|
Nut 1/4-20 hex nylon lock type NE stainless steel |
$1.18
|
1 |
|
ships same day |
31 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
$0.99
|
10 |
|
ships same day |
32 |
202-2067
|
Nut 10-32 keps |
$5.50
|
2 |
|
usually ships 3-11 days |
33 |
999-1466
|
Nut 1/4-20 lock with external toothed lockwasher SS |
$0.99
|
7 |
|
ships same day |
34 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.99
|
4 |
|
ships same day |
35 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
$0.99
|
9 |
|
ships same day |
36 |
999-0617
|
Washer 3/8 x 1 flat stainless steel |
$1.82
|
2 |
|
ships same day |
37 |
999-1569
|
Washer 3/4 flat stainless steel |
$2.11
|
1 |
|
ships same day |
38 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
$0.99
|
3 |
|
ships same day |
39 |
999-0659
|
Washer 3/8 medium split lock stainless steel |
$0.39
|
7 |
|
ships same day |
40 |
999-1044
|
Screw 10-32 x 3/4 pan head phillips stainless steel |
$0.99
|
2 |
|
ships same day |
41 |
999-1507
|
Screw 5/16-18 x 1 button head socket stainless steel |
$1.88
|
2 |
|
ships same day |
42 |
999-1400
|
Screw 1/4-20 x 1 3/4 carriage head stainless steel |
$5.50
|
2 |
|
ships same day |
43 |
999-1442
|
Bolt 1/4-20 x 1/2 carriage stainless steel |
$0.99
|
3 |
|
usually ships 1-5 days |
44 |
202-2851
|
Bolt 1/4-20 x 5/8 inch carriage head stainless steel |
$5.50
|
5 |
|
usually ships 3-11 days |
45 |
999-0967
|
Bolt 5/16-18 x 3/4 carriage head stainless steel |
$2.16
|
2 |
|
ships same day |
46 |
999-9066
|
Bolt 5/16-18 x 1 carriage head stainless steel |
$1.34
|
10 |
|
ships same day |
47 |
999-1578
|
Bolt 3/8-24 x 3 1/2 hex head socket zinc plated |
$2.24
|
1 |
|
ships same day |
48 |
202-4122
|
Spring |
$12.54
|
2 |
|
usually ships 1-5 days |
49 |
999-0304
|
Nut 1/4-20 nylon lock jam stainless steel |
$0.99
|
2 |
|
ships same day |
50 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
$0.99
|
6 |
|
ships same day |
51 |
999-0324
|
Nut 3/8-16 nylon insert lock jam zinc plated |
$0.99
|
1 |
|
ships same day |
52 |
202-2036
|
Cotter pin |
$8.25
|
1 |
|
usually ships 3-11 days |
53 |
202-3128
|
Sleeved bearing |
$5.50
|
8 |
|
usually ships 3-11 days |
54 |
202-4123
|
Plastic spacer |
$6.71
|
2 |
|
usually ships 1-5 days |
55 |
202-3415
|
Strap |
$5.50
|
1 |
|
usually ships 3-11 days |
56a |
202-4124
|
Hose 1/2 x 3 inch |
$5.50
|
1 |
(17 inch) |
usually ships 1-5 days |
56b |
202-4125
|
Hose 1/2 x 4 1/2 inch |
$4.95
|
1 |
(20 inch) |
usually ships 3-11 days |
57a |
202-4126
|
17 inch curtain band |
$32.01
|
1 |
|
usually ships 1-5 days |
57b |
202-4127
|
20 inch curtain band |
$24.42
|
1 |
|
usually ships 3-11 days |
58a |
202-4128
|
17 inch curtain |
$12.54
|
1 |
|
usually ships 1-5 days |
58b |
202-4129
|
20 inch curtain |
$15.40
|
1 |
|
usually ships 3-11 days |
