| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
202-2214
|
Axle |
$56.32
|
1 |
|
usually ships 1-5 days |
2 |
202-2216
|
Shaft collar with set screw |
$5.50
|
2 |
|
usually ships 3-11 days |
3 |
202-4147
|
Shim |
$4.62
|
4 |
|
usually ships 3-11 days |
4 |
999-0346
|
Screw 5/16-18 x 1/4 set cup point socket alloy plain finish |
$0.99
|
2 |
|
ships same day |
5 |
202-2048
|
3/4 inch snap ring |
$5.50
|
4 |
|
usually ships 3-11 days |
7 |
999-0593
|
Nut 5/16-18 hex stainless steel |
$0.99
|
12 |
|
ships same day |
8 |
999-0294
|
Nut 1/4-20 hex nylon lock type NE stainless steel |
$1.18
|
7 |
|
ships same day |
9 |
999-0617
|
Washer 3/8 x 1 flat stainless steel |
$1.82
|
8 |
|
ships same day |
10 |
999-0632
|
Washer 1/4 split lock stainless steel |
$0.99
|
4 |
|
ships same day |
11 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
$0.99
|
4 |
|
ships same day |
12 |
999-1571
|
Screw 1/4-20 x 3/4 flat head socket stainless steel |
$0.99
|
3 |
|
ships same day |
13 |
999-0734
|
Screw 5/16-18 x 1 3/4 flat head socket zinc plated |
$1.25
|
8 |
|
ships same day |
14 |
999-0917
|
U bolt |
$7.90
|
2 |
|
usually ships 11-24 days |
15 |
202-3415
|
Strap |
$5.50
|
3 |
|
usually ships 3-11 days |
16a |
202-2064
|
Caster wheel (red) |
$110.11
|
2 |
|
usually ships 3-11 days |
16b |
202-4143
|
Solid caster wheel (gray) |
$135.96
|
2 |
|
usually ships 3-11 days |
16c |
202-0919
|
Non-marking Soft caster wheel (gray) |
$149.16
|
2 |
|
usually ships 3-11 days |
17a |
202-2215
|
Tire (gray) |
$238.92
|
2 |
|
ships same day |
17b |
202-4149
|
Tire (black) |
$138.38
|
2 |
|
usually ships 3-11 days |
N/S |
999-1489
|
Screw 3/8-16 x 1 1/2 hex head stainless steel |
$1.72
|
1 |
|
ships same day |
