| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
202-4134
|
Main frame |
$443.19
|
1 |
|
usually ships 1-5 days |
2 |
202-4135
|
Left side frame support |
$23.32
|
1 |
|
usually ships 1-5 days |
3 |
202-4136
|
Right side frame support |
$23.32
|
1 |
|
usually ships 1-5 days |
4 |
202-4137
|
Spacer |
$22.37
|
2 |
|
usually ships 3-11 days |
5 |
202-1487
|
Latch |
$25.19
|
2 |
|
usually ships 3-11 days |
6 |
202-3543
|
10-24 x 1 threaded stud |
$6.71
|
4 |
|
ships same day |
7 |
999-1504
|
Nut 10-24 jam insert lock stainless steel |
$0.99
|
4 |
|
ships same day |
8 |
999-1489
|
Screw 3/8-16 x 1 1/2 hex head stainless steel |
$1.72
|
2 |
|
ships same day |
9 |
999-0593
|
Nut 5/16-18 hex stainless steel |
$0.99
|
1 |
|
ships same day |
10 |
999-0357
|
Nut 8-32 nylon insert lock stainless steel |
$0.99
|
4 |
|
ships same day |
11 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
$0.99
|
7 |
|
ships same day |
12 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
$0.99
|
1 |
|
ships same day |
13 |
999-0659
|
Washer 3/8 medium split lock stainless steel |
$0.39
|
2 |
|
ships same day |
14 |
999-0916
|
Screw 8-32 x 1/2 pan head phillips stainless steel |
$0.99
|
4 |
|
ships same day |
15 |
999-1494
|
Screw 5/16-18 x 3/4 flat head socket stainless steel |
$1.31
|
2 |
|
usually ships 11-24 days |
16 |
999-0967
|
Bolt 5/16-18 x 3/4 carriage head stainless steel |
$2.16
|
5 |
|
ships same day |
17 |
999-1577
|
Bolt 5/16-18 x 2 round head carriage stainless steel |
$1.84
|
1 |
|
usually ships 1-5 days |
18 |
999-0120
|
Washer 3/8 SAE flat |
$0.99
|
2 |
|
ships same day |
19 |
999-0617
|
Washer 3/8 x 1 flat stainless steel |
$1.82
|
1 |
|
ships same day |
20 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
$0.99
|
1 |
|
ships same day |
