| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-2094
|
20 inch Front Shroud |
1 |
|
|
2 |
202-2095
|
20 inch & 23 inch Shroud Curtain Band(OBSOLETE) |
1 |
|
|
3 |
202-2096
|
20 inch Shroud Curtain Band (OBSOLETE) |
1 |
|
|
4 |
202-2097
|
20 inch Shroud Curtain Front |
1 |
|
|
5 |
202-2098
|
4 inch wheel (gray) |
2 |
|
|
6 |
202-1487
|
Latch |
1 |
|
|
7 |
999-0295
|
Nut 4-40 nylon insert lock stainless steel |
2 |
|
|
8 |
999-0086
|
Nut 10-32 nylon insert lock zinc plated |
2 |
|
|
9 |
999-1467
|
Screw #10-32 x 5/8 round head slotted stainless steel |
2 |
|
|
10 |
999-0941
|
Screw 4-40 x 1/4 pan head phillips stainless steel |
2 |
|
|
11 |
202-2100
|
Bolt 5/16-18 x 2 carriage head |
2 |
|
|
12 |
999-0617
|
Washer 3/8 x 1 flat stainless steel |
2 |
|
|
13 |
999-1019
|
Nut 5/16-18 hex jam stainless steel |
2 |
|
|
