| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-2219
|
Main frame |
1 |
|
|
2 |
202-4165
|
24V 50amp relay |
2 |
|
|
3 |
202-2052
|
15amp circuit breaker |
1 |
|
|
4 |
202-3543
|
10-24 x 1 threaded stud |
2 |
|
|
5 |
999-1269
|
Nut 10-32 nylon insert jam stainless steel |
2 |
|
|
6 |
999-0241
|
Nut 3/8-16 heavy hex hot dip galvanized |
2 |
|
|
7 |
999-0609
|
Nut 1/4-20 hex stainless steel |
8 |
|
|
8 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
3 |
|
|
9 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
4 |
|
|
10 |
999-0998
|
Washer #10 flat stainless steel |
2 |
|
|
11 |
999-0632
|
Washer 1/4 split lock stainless steel |
8 |
|
|
12 |
999-6707
|
Screw #10-32 x 1/2 round head phillips stainless steel |
4 |
|
|
13 |
999-1401
|
Bolt 1/4-20 x 1 carriage head stainless steel |
4 |
|
|
14 |
999-0967
|
Bolt 5/16-18 x 3/4 carriage head stainless steel |
3 |
|
|
15 |
202-2217
|
Standoff 10-32 x 7/8 (OBSOLETE) |
2 |
|
|
