| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-0811
|
Double ended stud |
1 |
|
|
2 |
202-2205
|
Tube |
2 |
|
|
3 |
202-2206
|
Squeegee swing plate |
1 |
|
|
4 |
202-2207
|
Squeegee trail arm |
1 |
|
|
5a |
202-0809
|
Brass star knob |
1 |
|
|
5b |
991-2411
|
Brass star knob |
1 |
(NON-OEM) |
|
6 |
202-0813
|
Spring |
1 |
|
|
7 |
202-0808
|
Squeegee triangle plate |
1 |
|
|
8 |
202-2208
|
Compression spring |
2 |
|
|
9 |
202-0151
|
Grommet |
3 |
|
|
10 |
999-1151
|
Nut 3/8-24 nylon insert jam lock stainless steel |
2 |
|
|
11 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
1 |
|
|
12 |
202-2210
|
Washer 3/8 x 3/4 flat nylon |
4 |
|
|
13 |
999-0562
|
Bolt 3/8-16 x 1 hex head stainless steel |
2 |
|
|
14 |
202-2211
|
Screw 3/8-16 x 2 hex cap stainless steel |
1 |
|
|
15 |
999-0994
|
Screw 3/8-24 x 2 1/4 hex head stainless steel |
1 |
|
|
16 |
999-0617
|
Washer 3/8 x 1 flat stainless steel |
3 |
|
|
17 |
999-0513
|
Nut 3/8-16 nylon insert lock type NE stainless steel |
3 |
|
|
18 |
999-1019
|
Nut 5/16-18 hex jam stainless steel |
2 |
|
|
