| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
202-2200
|
Actuator bracket |
1 |
|
|
2 |
202-2201
|
Actuator weldment |
1 |
|
|
3 |
202-0946
|
Down pressure spring |
2 |
|
|
4 |
202-1239
|
Flanged bearing |
2 |
|
|
5 |
202-1186
|
Bolt 3/8-24 x 1 1/8 hex cap stainless steel |
1 |
|
|
6 |
999-0297
|
Bolt 1/4-20 x 1 hex head stainless steel |
4 |
|
|
7 |
999-0609
|
Nut 1/4-20 hex stainless steel |
6 |
|
|
8 |
999-0169
|
Nut 3/8-24 hex jam plain finish |
1 |
|
|
9 |
999-0632
|
Washer 1/4 split lock stainless steel |
4 |
|
|
10 |
999-0304
|
Nut 1/4-20 nylon lock jam stainless steel |
2 |
|
|
11 |
202-2036
|
Cotter pin |
1 |
|
|
12 |
202-5193
|
Clevis pin 3/8 x 2 |
1 |
|
|
