| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
202-0703
|
Elbow |
1 |
|
|
002 |
202-2025
|
Hosebarb |
1 |
|
|
003 |
202-2103
|
Wire reinforced Clear hose |
1 |
|
|
004 |
202-2104
|
Wire Reinforced Black Hose |
1 |
|
|
005 |
202-2105
|
Clear hose |
1 |
|
|
006 |
202-2106
|
Solution / Recovery Tank |
1 |
|
|
007 |
202-2107
|
Elbow 1/2 inch Male |
1 |
|
|
008 |
202-2108
|
Nylon elbow |
1 |
|
|
009a |
202-0708
|
Drain hose |
1 |
|
|
009b |
991-2415
|
Drain hose |
1 |
(NON-OEM) |
|
010 |
202-2110
|
J-Hook |
1 |
|
|
011 |
202-0706
|
1 1/2 inch hose cuff |
1 |
|
|
012 |
202-1649
|
1/2 NPT TO 1/2 inch HOSE BARB, BRASS |
1 |
|
|
013 |
202-2111
|
2 inch hose cuff |
1 |
|
|
014 |
202-1487
|
Latch |
2 |
|
|
015 |
997-2011
|
Hose clamp |
1 |
|
|
016 |
202-2112
|
Pin (OBSOLETE) |
2 |
|
|
017 |
202-0846
|
Rubber loop clamp |
3 |
|
|
018 |
202-2066
|
Hose clamp |
2 |
|
|
019 |
999-0334
|
Bolt 1/4-20 x 3/4 inch hex head stainless steel |
3 |
|
|
020 |
999-0609
|
Nut 1/4-20 hex stainless steel |
1 |
|
|
021 |
999-0632
|
Washer 1/4 split lock stainless steel |
3 |
|
|
022 |
999-0334
|
Bolt 1/4-20 x 3/4 inch hex head stainless steel |
4 |
|
|
