| # | Part | Description | Price | Req | Notes | Availability |
|---|
001 |
202-1846
|
Left shroud 17 inch |
$256.96
|
1 |
|
usually ships 1-5 days |
002 |
202-1847
|
Right shroud 17 inch |
$239.69
|
1 |
|
usually ships 1-5 days |
003 |
202-1848
|
Bandeau cover |
$620.95
|
1 |
|
usually ships 1-5 days |
004 |
202-1849
|
Shroud splash curtain 17 inch |
$252.67
|
1 |
|
usually ships 1-5 days |
005 |
202-1850
|
End shroud support |
$28.16
|
2 |
|
usually ships 1-5 days |
006 |
202-1851
|
Right shroud band 17 inch (OBSOLETE) |
$32.32
|
1 |
|
usually ships 1-5 days |
007 |
202-1852
|
Roller bracket (OBSOLETE) |
Call for price
|
2 |
|
usually ships 1-5 days |
008 |
202-1853
|
Left shroud band (OBSOLETE) |
$74.61
|
1 |
|
usually ships 1-5 days |
009 |
202-1854
|
Center shroud support |
$28.60
|
1 |
|
usually ships 1-5 days |
010 |
202-0756
|
Guide roller |
$28.16
|
2 |
|
usually ships 8-12 days |
011 |
202-0969
|
Shroud hinge |
$5.50
|
1 |
|
usually ships 1-5 days |
012 |
202-0174
|
Squeegee guide wheels w/ collar and hardware (pkg of 2) |
$50.49
|
2 |
set of two with hardware |
usually ships 8-12 days |
013 |
202-1044
|
Nut wing 3/8-16 nickel |
$13.75
|
2 |
|
ships same day |
014 |
202-0620
|
Scrub head platform (OBSOLETE) |
$454.52
|
1 |
|
usually ships 8-12 days |
015 |
999-1209
|
Bolt 5/8-11 x 4 hex head zinc plated |
$6.09
|
2 |
|
ships same day |
016 |
999-0968
|
Nut 5/8-11 nylon insert jam lock zinc plated |
$2.27
|
2 |
|
ships same day |
017 |
999-0644
|
Bolt 1/4-20 x 1/2 hex head stainless steel |
$0.99
|
4 |
|
ships same day |
018 |
999-0334
|
Bolt 1/4-20 x 3/4 inch hex head stainless steel |
$3.85
|
20 |
|
ships same day |
019 |
999-0911
|
Screw 5/16-18 x 3 hex head stainless steel |
$4.75
|
2 |
|
ships same day |
020 |
999-0493
|
Bolt 3/8-16 x 3/4 hex head stainless steel |
$0.99
|
2 |
|
ships same day |
021 |
999-0609
|
Nut 1/4-20 hex stainless steel |
$0.99
|
18 |
|
ships same day |
022 |
999-0593
|
Nut 5/16-18 hex stainless steel |
$0.99
|
6 |
|
ships same day |
023 |
999-0086
|
Nut 10-32 nylon insert lock zinc plated |
$0.99
|
13 |
|
ships same day |
024 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.99
|
14 |
|
ships same day |
025 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
$0.99
|
4 |
|
ships same day |
026 |
999-0632
|
Washer 1/4 split lock stainless steel |
$0.99
|
24 |
|
ships same day |
027 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
$0.99
|
2 |
|
ships same day |
028 |
999-1009
|
Screw 10-32 x 1/2 flat head phillips stainless steel |
$0.99
|
13 |
|
ships same day |
