| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
201-2176
|
Boom arm support |
1 |
|
|
2 |
201-2153
|
Pillow block bearing |
1 |
|
|
3 |
999-0024
|
Washer 5/16 flat stainless steel |
2 |
|
|
4 |
201-1072
|
Washer |
1 |
|
|
5 |
999-0107
|
Bolt 3/8-16 x 2 hex head grade 5 zinc plated |
2 |
|
|
6 |
201-2177
|
Pulley MB 78 x 1 |
1 |
|
|
7 |
201-2154
|
Input pulley shaft |
1 |
|
|
8 |
201-0017
|
Square keyway |
1 |
|
|
9 |
201-2155
|
1 inch external retaining ring |
1 |
|
|
