| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
295-8519
|
Handle screw assembly |
2 |
|
|
3 |
295-8520
|
Hose assembly (OBSOLETE) |
1 |
|
|
4 |
295-8521
|
Lower hose assembly (OBSOLETE) |
1 |
|
|
5a |
295-8522
|
Nozzle cover assembly (red) (OBSOLETE) |
1 |
|
|
5b |
295-8523
|
Nozzle guard |
1 |
|
|
6 |
295-8524
|
Bottom plate |
1 |
|
|
7 |
295-8525
|
Brush roll assembly (OBSOLETE) |
1 |
|
|
8 |
295-8526
|
Extension wand |
1 |
|
|
9 |
295-8527
|
12 amp motor assembly |
1 |
|
|
10 |
295-8528
|
Power cord |
1 |
|
|
11 |
228-2012
|
F-1 Hepa filter |
1 |
|
|
12 |
295-8529
|
Crevice tool |
1 |
|
|
13 |
295-8530
|
2 in 1 brush assembly (OBSOLETE) |
1 |
|
|
15 |
295-8532
|
Cord hook (black) |
1 |
|
|
16 |
295-8533
|
Switch assembly |
1 |
|
|
17 |
295-8534
|
Belt guide clip (OBSOLETE) |
1 |
|
|
18 |
295-8535
|
Handle release pedal (OBSOLETE) |
1 |
|
|
19 |
295-8536
|
Dirt cup assembly |
1 |
|
|
20 |
295-8537
|
Grommet |
1 |
|
|
21 |
295-8538
|
Switch pedal |
1 |
|
|
22 |
295-8539
|
Bumper |
1 |
|
|
23 |
295-8540
|
Roller lifter assembly (OBSOLETE) |
2 |
|
|
25 |
295-8541
|
Rear wheel (OBSOLETE) |
1 |
|
|
26 |
295-8542
|
Tool caddy |
1 |
|
|
27 |
295-8543
|
Rear wheel cap (OBSOLETE) |
1 |
|
|
28 |
295-8544
|
Nozzle base |
1 |
|
|
29 |
295-8545
|
Dirt cup latch (OBSOLETE) |
1 |
|
|
30 |
295-8546
|
Dirt cup latch spring |
1 |
|
|
31 |
295-8547
|
Clear dirt tube |
1 |
|
|
32 |
295-8548
|
Lower motor housing (OBSOLETE) |
1 |
|
|
33 |
295-8549
|
Dirt passage door (OBSOLETE) |
1 |
|
|
