| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
193-1599
|
850mm aluminum squeegee casting |
$224.00
|
1 |
|
usually ships 16-24 days |
2 |
193-1598
|
850mm blade holder |
$54.10
|
1 |
|
usually ships 16-24 days |
3 |
193-1603
|
Squeegee blade kit 850mm polyurethane (green) |
$177.28
|
1 |
|
usually ships 16-24 days |
4 |
193-1603
|
Squeegee blade kit 850mm polyurethane (green) |
$177.28
|
1 |
|
usually ships 16-24 days |
5a |
193-1588
|
M10 lobe knob (red) |
$20.94
|
4 |
(after SN 1812) |
usually ships 16-24 days |
5b |
193-1577
|
Lobe knob |
$9.56
|
4 |
(before SN 1813) |
usually ships 16-24 days |
6 |
193-1604
|
Washer M10 single coil stainless steel |
$3.76
|
2 |
|
usually ships 16-24 days |
7 |
999-1953
|
Screw M6-1 x 35mm socket stainless steel |
$2.07
|
6 |
|
ships same day |
8 |
220-4090
|
Washer |
$3.36
|
6 |
|
usually ships 16-24 days |
9 |
193-1468
|
Detent pins |
$12.99
|
4 |
|
usually ships 16-24 days |
10 |
193-0139
|
Nut M6 nylon insert stainless steel |
$5.50
|
6 |
|
ships same day |
11 |
193-1479
|
Screw M10 x 25mm hex head stainless steel |
$3.29
|
2 |
|
usually ships 16-24 days |
12 |
193-1578
|
Right hand clip |
$9.83
|
1 |
|
usually ships 16-24 days |
13 |
193-1579
|
Left hand clip |
$9.83
|
1 |
|
usually ships 16-24 days |
14 |
193-1580
|
4 inch wheel |
$32.64
|
2 |
|
usually ships 16-24 days |
15 |
193-1583
|
Conical spring |
$17.56
|
2 |
|
usually ships 16-24 days |
16a |
193-1589
|
50mm TPR tyreed swivel castor (grey) |
$17.48
|
2 |
(after SN 1812) |
usually ships 16-24 days |
16b |
193-1584
|
50mm tyred swivel caster (grey) |
$11.89
|
2 |
(before SN 1813) |
usually ships 16-24 days |
17 |
193-1590
|
13mm wave washer |
$3.32
|
2 |
|
usually ships 16-24 days |
18a |
193-1591
|
Left hand adjustable plastic caster plate |
$7.12
|
1 |
(after SN 1812) |
usually ships 16-24 days |
18b |
193-1594
|
Right hand caster plate weldment assembly |
$25.23
|
1 |
(before SN 1813) |
usually ships 16-24 days |
19a |
193-1592
|
Right hand adjustable plastic caster plate |
$7.12
|
1 |
(after SN 1812) |
usually ships 16-24 days |
19b |
193-1595
|
Left hand caster plate weldment assembly |
$26.21
|
1 |
(before SN 1813) |
usually ships 16-24 days |
20 |
193-1606
|
Washer M10 penny stainless steel |
$3.64
|
2 |
(after SN 1812) |
usually ships 16-24 days |
21 |
193-1593
|
Nut M10 hex lock stainless steel |
$3.22
|
2 |
(after SN 1812) |
usually ships 16-24 days |
