| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
193-1596
|
Squeegee casting |
$167.67
|
|
|
usually ships 16-24 days |
2 |
193-1570
|
Caster plate |
$31.14
|
|
|
usually ships 16-24 days |
3 |
220-0220
|
3 inch wheel |
$34.83
|
|
|
usually ships 16-24 days |
4 |
193-1571
|
50mm caster |
$74.09
|
|
|
usually ships 16-24 days |
5 |
193-1603
|
Squeegee blade kit 850mm polyurethane (green) |
$154.89
|
|
(650) (rear) |
usually ships 16-24 days |
6 |
193-1603
|
Squeegee blade kit 850mm polyurethane (green) |
$154.89
|
|
(850) (front) |
usually ships 16-24 days |
7 |
193-1569
|
Quick release knob |
$52.97
|
|
|
usually ships 16-24 days |
8 |
193-1468
|
Detent pins |
$34.08
|
|
|
usually ships 16-24 days |
9 |
220-4090
|
Washer |
$2.93
|
|
|
usually ships 16-24 days |
10 |
193-1520
|
M6 nyloc half nut |
Call for price
|
|
|
usually ships 16-24 days |
11 |
999-1953
|
Screw M6-1 x 35mm socket stainless steel |
$2.07
|
|
|
ships same day |
12 |
999-1120
|
Nut M10-1.5 nylon insert lock stainless steel |
$3.92
|
|
|
ships same day |
13 |
193-1438
|
Screw M10 x 25mm button head socket stainless steel |
$2.96
|
|
|
usually ships 16-24 days |
14 |
193-1598
|
850mm blade holder |
$42.41
|
|
(850) |
usually ships 16-24 days |
15 |
999-6697
|
Nut M10-1.5 hex stainless steel |
$1.01
|
|
|
ships same day |
16 |
193-1467
|
Welded tube/plate assembly |
$152.98
|
|
(after SN 0924) |
usually ships 16-24 days |
