| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
220-0357
|
Squeegee weldment |
$182.85
|
|
(38mm hose fitting) |
usually ships 16-24 days |
2 |
193-1572
|
650mm blade holder moulding |
$50.33
|
|
(32mm & 38mm hose fitting) (sloping profile) |
usually ships 16-24 days |
3a |
193-0095
|
Squeegee blade kit 26 inch |
$141.12
|
|
(standard blade option) (847mm long) |
usually ships 16-24 days |
3b |
193-1573
|
Squeegee blade 650mm poly rear |
Call for price
|
|
(premium blade option) (847mm long) |
usually ships 16-24 days |
3c |
193-0095
|
Squeegee blade kit 26 inch |
$141.12
|
|
(premium blade option) (847mm long) |
usually ships 16-24 days |
4a |
193-0095
|
Squeegee blade kit 26 inch |
$141.12
|
|
(standard blade option) (819mm long) |
usually ships 16-24 days |
4b |
193-1574
|
Squeegee blade 650mm poly front |
Call for price
|
|
(premium blade option) (819mm long) |
usually ships 16-24 days |
4c |
193-0095
|
Squeegee blade kit 26 inch |
$141.12
|
|
(premium blade option) (819mm long) |
usually ships 16-24 days |
5 |
193-1569
|
Quick release knob |
$73.37
|
|
|
usually ships 16-24 days |
6 |
193-1570
|
Caster plate |
$43.13
|
|
|
usually ships 16-24 days |
7 |
999-6697
|
Nut M10-1.5 hex stainless steel |
$1.01
|
|
|
ships same day |
8 |
193-1367
|
Nut nylon insert |
$3.32
|
|
|
usually ships 16-24 days |
9 |
193-1438
|
Screw M10 x 25mm button head socket stainless steel |
$3.41
|
|
|
usually ships 16-24 days |
10 |
193-1571
|
50mm caster |
$84.80
|
|
|
usually ships 16-24 days |
11 |
999-1953
|
Screw M6-1 x 35mm socket stainless steel |
$2.07
|
|
|
ships same day |
12 |
220-4090
|
Washer |
$3.36
|
|
|
usually ships 16-24 days |
13 |
220-0220
|
3 inch wheel |
$39.85
|
|
|
usually ships 16-24 days |
14 |
193-1468
|
Detent pins |
$12.99
|
|
|
usually ships 16-24 days |
15 |
193-1520
|
M6 nyloc half nut |
Call for price
|
|
|
usually ships 16-24 days |
16 |
193-1467
|
Welded tube/plate assembly |
$211.92
|
|
|
usually ships 16-24 days |
