| # | Part | Description | Price | Req | Notes | Availability |
|---|
101 |
192-4577
|
Insulating nut |
$23.16
|
1 |
|
ships same day |
102 |
192-1420
|
75amp fuse |
$17.51
|
1 |
|
usually ships 17-21 days |
103 |
192-2505
|
Battery cable clamp |
$23.54
|
1 |
|
ships same day |
104 |
192-1926
|
Negative battery clamp |
$5.98
|
1 |
|
ships same day |
105 |
192-1927
|
Positive battery clamp |
$7.49
|
1 |
|
ships same day |
106a |
192-4224
|
Screw M6 x 35mm hex head |
$2.89
|
1 |
(series 01 and 02) |
usually ships 17-21 days |
106b |
192-9355
|
Screw M6 x 40mm hex head |
$4.24
|
1 |
(series 03) |
ships same day |
107 |
192-0151
|
Nut M6 hex |
$2.56
|
1 |
|
ships same day |
108 |
192-0886
|
Battery post cover |
$3.08
|
1 |
|
ships same day |
109a |
192-9328
|
Jumper (OBSOLETE) |
$2.44
|
1 |
(non BMS) (power) |
usually ships 17-21 days |
109b |
192-8806
|
Jumper |
$2.56
|
1 |
(non BMS) (eco) |
ships same day |
110 |
192-0389
|
50amp charger plug SB50 with hole (gray) |
$17.51
|
1 |
|
ships same day |
111 |
192-0388
|
50amp charger plug SB50 with post (gray) |
$8.86
|
1 |
|
ships same day |
112a |
192-4658
|
Key switch assembly (OBSOLETE) |
$48.14
|
1 |
(includes 113 and 115) (series 01 and 02) |
usually ships 17-21 days |
112b |
292-5708
|
Key switch |
$23.46
|
1 |
(includes 113, 115-116) (series 03) |
ships same day |
113 |
292-5254
|
Steel key |
$3.97
|
1 |
|
ships same day |
115 |
192-8584
|
Screw 40 x 8 |
$2.56
|
1 |
|
usually ships 17-21 days |
116 |
192-0149
|
Washer |
$2.56
|
1 |
(series 03) |
ships same day |
117 |
192-7083
|
T-handle |
$58.28
|
1 |
(series 03) (optional) |
ships same day |
122 |
192-9546
|
Wiring harness (BAS switch to pump and solution valve) |
$22.06
|
1 |
|
ships same day |
123 |
192-9329
|
Communication cable (dashboard to power electronic) |
$14.10
|
1 |
|
ships same day |
124 |
192-9548
|
Wiring harness (power board to batteries) |
$78.16
|
1 |
(includes 111 and 131) |
usually ships 17-21 days |
125 |
192-9549
|
Cable (dashboard to charger) |
$32.95
|
1 |
(includes 131) (power model) |
usually ships 17-21 days |
126a |
192-2482
|
Wire assembly with small SB50 red connector |
$12.69
|
1 |
(series 01 and 02) |
usually ships 1-5 days |
126b |
292-8614
|
Wire harness |
$15.13
|
1 |
(series 03) |
usually ships 17-21 days |
126c |
292-8615
|
Ribbon cable 4-pol |
$91.62
|
1 |
(series 03) (855R) |
usually ships 17-21 days |
127a |
192-2512
|
Cable assembly (OBSOLETE) |
$32.48
|
1 |
(series 01 and 02) |
usually ships 17-21 days |
127b |
292-8616
|
Wire harness |
$35.00
|
1 |
(series 03) |
usually ships 17-21 days |
128 |
192-7536
|
Wiring harness - Anderson to battery |
$225.34
|
1 |
|
usually ships 17-21 days |
129a |
192-7537
|
Wiring harness - Anderson to board (OBSOLETE) |
$91.82
|
1 |
(includes 111) (series 01 and series 02) |
usually ships 17-21 days |
129b |
292-8617
|
Wire harness |
$143.29
|
1 |
(includes 111) (series 03) |
usually ships 17-21 days |
130 |
192-1406
|
Battery cable |
$64.36
|
1 |
|
ships same day |
131 |
192-0712
|
Coil with toric core |
$7.13
|
1 |
(power model) |
usually ships 17-21 days |
133 |
192-9553
|
Wiring harness (power board to J-fit option) |
$18.46
|
1 |
(power model) |
usually ships 17-21 days |
137 |
192-9545
|
Wiring harness (vac motor to control board) |
$43.59
|
1 |
(series 03) |
ships same day |
