| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
192-4052
|
Grid |
1 |
|
|
2a |
292-0727
|
Housing set |
1 |
(for all other BP models) |
|
2b |
292-8668
|
Housing set |
1 |
(for BP E/B/B models) |
|
3 |
292-0728
|
Cover set |
1 |
(includes 4 and 5) |
|
4 |
192-1750
|
Door latch set |
1 |
|
|
5 |
292-0729
|
Blower door set |
1 |
|
|
6a |
292-8669
|
240V 50-60 hz 750W vacuum motor |
1 |
|
|
6b |
292-0730
|
120V vacuum motor |
1 |
|
|
6c |
292-0731
|
36V vacuum motor |
1 |
(Aero B Li-Ion) |
|
6d |
292-8670
|
36V 340W vacuum motor set |
1 |
(Aero B Li-Ion Plus) |
|
7a |
292-0732
|
Handle with valve |
1 |
(Aero BP E) |
|
7b |
192-1790
|
Handle |
1 |
(Aero BP B) |
|
8 |
292-0733
|
Latch set |
1 |
|
|
9 |
292-0734
|
Valve set |
1 |
(Aero BP E) |
|
10 |
292-0735
|
Gasket set |
1 |
|
|
11 |
292-0736
|
Motor housing set |
1 |
|
|
12 |
192-1848
|
Filter |
1 |
|
|
13 |
292-0737
|
Connector |
1 |
|
|
14a |
292-0738
|
Vacuum bag (pkg of 10) |
1 |
|
|
14b |
228-2876
|
Paper vacuum bags (pkg of 8 bags w/ 3 filters) LB4 bags |
1 |
|
|
15 |
292-0739
|
Motor foam filter |
1 |
|
|
16a |
192-9456
|
Micro-filter (pkg of 5) |
1 |
|
|
16b |
192-9457
|
HEPA filter |
1 |
|
|
