| # | Part | Description | Price | Req | Notes | Availability |
|---|
121 |
192-8970
|
Rear panel |
$48.92
|
1 |
|
ships same day |
122 |
192-1557
|
Screw 60 x 35 torx head |
$2.44
|
6 |
|
ships same day |
123 |
192-0236
|
Threaded cap (blue) |
$2.44
|
1 |
(series 1-3) |
ships same day |
124 |
192-0979
|
Hose |
$27.18
|
1 |
(series 1-3) |
ships same day |
125 |
192-8971
|
Drain hose with attached gray cap |
$99.22
|
1 |
|
ships same day |
126 |
192-1561
|
Screw 60 x 20 torx head |
$2.44
|
9 |
|
ships same day |
127 |
192-0099
|
Hose holder |
$1.79
|
2 |
|
ships same day |
129 |
192-2550
|
Holder |
$2.88
|
3 |
|
ships same day |
130 |
192-0130
|
Hose clamp |
$2.44
|
3 |
|
ships same day |
131 |
192-8972
|
Suction hose |
$46.40
|
1 |
|
ships same day |
132 |
292-0271
|
Rubber ring (red) |
$2.44
|
1 |
|
ships same day |
133 |
292-5284
|
Rubber ring (blue) |
$2.44
|
1 |
|
ships same day |
135 |
192-8984
|
Y-pipe |
$8.25
|
1 |
(series 1-3) |
ships same day |
136a |
192-8991
|
Squeegee suction hose |
$23.88
|
2 |
(1650) (must purchase reference 131 for complete squeegee hose assembly) |
ships same day |
136b |
192-9331
|
Squeegee suction hose |
$27.30
|
2 |
(1850) (must purchase reference 131 for complete squeegee hose assembly) |
ships same day |
137 |
292-5410
|
Cover |
$26.00
|
1 |
|
usually ships 30-75 days |
138 |
292-5411
|
Cover |
$11.23
|
1 |
|
ships same day |
139 |
192-1595
|
Screw M40 x 16mm torx head |
$2.44
|
2 |
|
ships same day |
140 |
292-5409
|
Cover |
$28.33
|
1 |
(series 1-3) |
usually ships 30-75 days |
141 |
292-5408
|
Rear cover |
$34.39
|
1 |
|
usually ships 30-75 days |
142 |
192-0549
|
Screw KA 35 x 20 |
$2.44
|
2 |
|
ships same day |
143 |
991-2103
|
50amp charger plug SB50 with pins (red) |
$6.17
|
1 |
(series 1-3) (for off board charger) |
usually ships 5-16 days |
144 |
192-8784
|
Switch lever |
$21.98
|
1 |
(for off board charger) |
ships same day |
145 |
192-9941
|
Wire harness with charger switch |
$63.01
|
1 |
(for off board charger) |
ships same day |
