| # | Part | Description |
Req | Notes | Availability |
|---|
101 |
192-0334
|
Hose clamp |
1 |
|
|
102 |
192-7215
|
Union stem 10 |
1 |
|
|
103 |
192-0404
|
Wire reinforced hose (sold by the inch) |
17 in |
|
|
104 |
192-0892
|
Silicone hose (sold by the inch) |
17 in |
|
|
106 |
192-0404
|
Wire reinforced hose (sold by the inch) |
13 in |
|
|
107 |
192-0400
|
Wire reinforced hose (sold by the inch) |
4 in |
|
|
108 |
192-9323
|
Union stem (OBSOLETE) |
1 |
|
|
109 |
N/A
|
Not available |
1 |
Solution tank |
|
110 |
N/A
|
Not available |
1 |
Filter |
|
111 |
192-5169
|
Nipple (OBSOLETE) |
1 |
|
|
112 |
192-3922
|
Gasket (OBSOLETE) |
1 |
|
|
113 |
192-0603
|
Screw hex |
1 |
|
|
114a |
192-1338
|
Knob |
2 |
|
|
114b |
192-1342
|
Bracket (OBSOLETE) |
1 |
|
|
115 |
N/A
|
Not available |
1 |
Magnetic valve |
|
116 |
192-7951
|
Screwing socket 3/4 inch (OBSOLETE) |
1 |
|
|
117 |
192-5168
|
Nipple |
1 |
|
|
