| # | Part | Description |
Req | Notes | Availability |
|---|
101a |
192-5078
|
24V brush motor with noise suppression |
1 |
|
|
101b |
192-0797
|
Carbon brush with holder (OBSOLETE) |
1 |
|
|
102 |
192-5275
|
Noise suppressing condenser (OBSOLETE) |
1 |
|
|
103 |
192-2485
|
Cable assembly (OBSOLETE) |
1 |
|
|
104 |
192-0712
|
Coil with toric core |
1 |
|
|
105 |
192-8633
|
Stud |
3 |
|
|
106 |
192-5815
|
Pulley |
1 |
|
|
107 |
192-5942
|
Screw M6 x 16mm raised cheese head torx |
2 |
|
|
108 |
192-2979
|
Screw M6 x 16mm countersunk head cap |
1 |
|
|
109 |
192-0800
|
Nut M12 left hand thread hex |
1 |
|
|
110 |
192-0200
|
Washer M6 |
2 |
|
|
