| # | Part | Description | Price | Req | Notes | Availability |
|---|
701a |
192-0264
|
Screw M10 x 20mm socket head cap |
$5.86
|
7 |
(series 2 and series 3) (06.1994 to 06.1995) |
usually ships 30-75 days |
701b |
192-8683
|
Screw 3/8 x 3/4 socket head cap (OBSOLETE) |
Call for price
|
7 |
(series 1) (before 11.1992) |
usually ships 1-5 days |
702a |
192-0265
|
24V motor |
$1,114.43
|
1 |
|
usually ships 1-5 days |
702b |
192-0266
|
Carbon brush (pkg of 4) |
$124.74
|
1 |
|
usually ships 30-75 days |
703 |
192-0267
|
Keyway |
$2.44
|
1 |
|
usually ships 30-75 days |
704a |
192-0268
|
Drive gear |
$105.86
|
1 |
(series 2 and series 3) (06.1994 to 06.1995) |
usually ships 1-5 days |
704b |
192-0268
|
Drive gear |
$105.86
|
1 |
(series 1) (before 11.1992) |
usually ships 1-5 days |
705 |
192-0269
|
Washer |
$2.44
|
1 |
|
usually ships 30-75 days |
706 |
999-0507
|
Bolt M6-1 x 16mm hex head full thread plain finish |
$0.99
|
1 |
|
ships same day |
707 |
192-0270
|
Woodruff keyway |
$24.06
|
1 |
|
usually ships 1-5 days |
708a |
192-0271
|
Magnetic brake complete |
$606.72
|
1 |
|
usually ships 30-75 days |
708b |
192-0272
|
2-pole plug |
$2.44
|
1 |
|
usually ships 1-5 days |
708c |
192-0058
|
Plug pin |
$2.44
|
2 |
(series 3) (after 06.1995) |
usually ships 30-75 days |
708d |
192-5602
|
Plug pin (OBSOLETE) |
$2.20
|
2 |
(series 2) (before 06.1995) |
usually ships 1-5 days |
709 |
192-0075
|
Retaining ring |
$5.81
|
1 |
|
ships same day |
710a |
192-0273
|
Drive unit |
$16,640.97
|
1 |
(series 2 and series 3) (06.1994 to 06.1995) |
usually ships 1-5 days |
710b |
192-0274
|
Shaft seal 20 x 35 x 7 |
$11.89
|
1 |
(series 2 and series 3) (06.1994 to 06.1995) |
usually ships 30-75 days |
710c |
192-0275
|
Shaft seal 25 x 35 x 7 |
$10.99
|
1 |
(series 2 and series 3) (06.1994 to 06.1995) |
usually ships 30-75 days |
710d |
192-0273
|
Drive unit |
$16,640.97
|
2 |
(series 1) (before 11.1992) |
usually ships 1-5 days |
711a |
192-0276
|
Wheel hub |
$125.47
|
2 |
(series 2 and series 3) (06.1994 to 06.1995) |
usually ships 1-5 days |
711b |
N/A
|
Not available |
Call for price
|
2 |
(series 1) (before 11.1992) (wheel hub) |
usually ships 3-26 days |
712 |
192-0277
|
Screw M8 x 35mm socket head cap |
$0.89
|
2 |
|
ships same day |
713 |
192-6549
|
Special screw M3 (OBSOLETE) |
$37.47
|
2 |
|
usually ships 1-5 days |
714 |
192-0278
|
Screw M8 x 25mm socket head |
$0.89
|
6 |
|
ships same day |
715a |
192-0279
|
Wheel cover w/springs (OBSOLETE) |
$12.09
|
2 |
|
usually ships 30-75 days |
715b |
192-0280
|
Spring (OBSOLETE) |
$2.20
|
6 |
|
usually ships 1-5 days |
717 |
192-0105
|
Washer M8 |
$2.44
|
6 |
|
ships same day |
730a |
192-1431
|
Drive wheel assembly with tire, tube and hub (OBSOLETE) |
$171.24
|
2 |
(series 2 and series 3) (06.1994 to 06.1995) |
usually ships 30-75 days |
730b |
192-8649
|
Drive wheel assembly (OBSOLETE) |
$199.21
|
2 |
(series 1) (before 11.1992) |
usually ships 1-5 days |
731a |
192-4996
|
Complete drive wheel with air tube - black (OBSOLETE) |
$125.69
|
2 |
(series 2 and series 3) (06.1994 to 06.1995) |
usually ships 30-75 days |
731b |
192-7205
|
Grey tire |
$56.36
|
2 |
(series 2 and series 3) (06.1994 to 06.1995) |
usually ships 1-5 days |
731c |
192-7204
|
Black tire (OBSOLETE) |
$50.35
|
2 |
(series 2 and series 3) (06.1994 to 06.1995) |
usually ships 1-5 days |
731d |
192-4560
|
Inner tube |
$29.82
|
2 |
(series 2 and series 3) (06.1994 to 06.1995) |
usually ships 1-5 days |
731e |
192-6061
|
Outer rim half |
$27.94
|
2 |
(series 2 and series 3) (06.1994 to 06.1995) |
usually ships 1-5 days |
731f |
192-6060
|
Inner rim half |
$27.35
|
2 |
(series 2 and series 3) (06.1994 to 06.1995) |
usually ships 1-5 days |
731g |
192-0510
|
Nut M8 self locking |
$2.44
|
6 |
(series 2 and series 3) (06.1994 to 06.1995) |
ships same day |
731h |
192-7201
|
Tire (OBSOLETE) |
$193.57
|
2 |
(series 1) (before 11.1992) |
usually ships 1-5 days |
