# | Part | Description | Price | Req | Notes | Availability |
000 |
292-0747
|
Brush drive assembly |
$3,193.25
|
1 |
(includes 101-157) |
usually ships 10-39 days |
101 |
192-4997
|
Support bracket with bearing kit |
$167.89
|
1 |
(includes support bracket and bearing) |
ships same day |
104 |
192-0066
|
Screw M6 x 25mm socket head cap |
$3.49
|
4 |
|
ships same day |
107 |
192-0082
|
Screw M8 x 40mm socket head cap |
$0.89
|
4 |
|
ships same day |
108 |
192-1866
|
Ball bearing |
$2.44
|
12 |
|
ships same day |
109 |
192-0105
|
Washer M8 |
$2.44
|
6 |
|
ships same day |
110 |
192-0348
|
Screw M8 x 12mm truss head |
$2.44
|
8 |
|
ships same day |
111 |
192-9224
|
Left hand brush housing |
$55.83
|
1 |
|
usually ships 10-39 days |
112 |
192-9212
|
Screw M8 x 40/22mm hex |
$4.35
|
2 |
|
ships same day |
113 |
192-8744
|
Wheel |
$31.57
|
2 |
|
ships same day |
114 |
192-0077
|
Screw M5 x 12mm socket head |
$0.89
|
8 |
|
ships same day |
115 |
192-0510
|
Nut M8 self locking |
$2.44
|
8 |
|
ships same day |
116 |
192-8749
|
Motor |
$358.84
|
2 |
|
ships same day |
118 |
192-0067
|
Washer 4 x 17 x 3 |
$2.22
|
4 |
|
ships same day |
120 |
192-9225
|
Toothed belt |
$27.42
|
2 |
|
ships same day |
121 |
192-9226
|
Bevel gear |
$19.78
|
4 |
|
ships same day |
122 |
192-0007
|
Screw M6 x 16mm socket head cap |
$2.44
|
16 |
|
ships same day |
123 |
192-9227
|
Flanged bearing |
$50.02
|
4 |
|
ships same day |
124 |
192-9228
|
Eccentric shaft |
$110.62
|
4 |
|
usually ships 10-39 days |
125 |
192-6345
|
Nut M6 self locking |
$2.44
|
12 |
|
ships same day |
126 |
192-9229
|
Flanged bearing |
$35.48
|
4 |
|
usually ships 10-39 days |
127 |
192-9230
|
Motor base plate |
$450.22
|
1 |
(includes 115, 156-157) |
ships same day |
128 |
192-9231
|
Right hand brush housing |
$61.12
|
1 |
|
ships same day |
129 |
192-6039
|
Retaining ring |
$2.44
|
4 |
|
ships same day |
130 |
192-0325
|
Washer |
$2.44
|
4 |
|
usually ships 10-39 days |
131 |
192-9195
|
Rubber bearing |
$2.22
|
2 |
|
ships same day |
132 |
192-9196
|
Retaining clip |
$2.29
|
2 |
|
usually ships 10-39 days |
133 |
192-0289
|
Screw M6 x 10mm socket head |
$2.22
|
4 |
|
ships same day |
134 |
192-9146
|
Ball bearing |
$19.36
|
4 |
|
ships same day |
135 |
192-0235
|
Nut M4 self locking |
$2.22
|
4 |
|
ships same day |
136 |
192-9232
|
Angled nipple |
$11.99
|
2 |
|
ships same day |
137 |
192-9233
|
O-ring |
$2.66
|
2 |
|
ships same day |
138 |
192-9234
|
Brush console with bracket |
$295.79
|
2 |
(includes 151-152) |
usually ships 10-39 days |
140 |
192-9235
|
Steel rope |
$27.82
|
2 |
|
usually ships 10-39 days |
141 |
192-0243
|
Screw M8 x 20mm socket head |
$2.22
|
2 |
|
usually ships 10-39 days |
142 |
192-4211
|
Nut M8 hex |
$2.44
|
2 |
|
ships same day |
143 |
192-0078
|
Screw M8 x 16mm socket head |
$2.44
|
2 |
|
ships same day |
145 |
292-0122
|
Bolt |
$42.80
|
1 |
|
usually ships 10-39 days |
146 |
192-9694
|
Stopple |
$2.44
|
1 |
|
ships same day |
147 |
192-0496
|
Washer M10 |
$2.44
|
1 |
|
ships same day |
148 |
192-0264
|
Screw M10 x 20mm socket head cap |
$0.89
|
1 |
|
ships same day |
149 |
292-0402
|
Plate |
$47.69
|
1 |
|
usually ships 10-39 days |
150 |
292-0403
|
Gasket |
$3.73
|
1 |
|
usually ships 10-39 days |
151 |
192-9321
|
Bracket |
$88.27
|
2 |
|
usually ships 10-39 days |
152 |
192-0786
|
Screw 4 x 10 socket head |
$2.44
|
4 |
|
ships same day |
153 |
192-9322
|
Bearing cover |
$6.22
|
4 |
|
ships same day |
154 |
192-0941
|
Screw M40 x M10 for plastic |
$1.60
|
2 |
|
ships same day |
155 |
192-9803
|
Bushing |
$2.52
|
2 |
|
ships same day |
156 |
192-0327
|
Screw M8 x 22 socket head cap |
$0.89
|
2 |
|
ships same day |
157 |
292-0404
|
Holder |
$17.05
|
1 |
|
usually ships 10-39 days |
N/S |
292-8528
|
.5ml capsule loctite medium strength thread lock (red) |
$55.00
|
1 |
|
ships same day |
N/S |
192-9210
|
Hose clamp |
$2.44
|
4 |
(included with KIT1) |
ships same day |
N/S |
192-0404
|
Wire reinforced hose (sold by the inch) |
$0.99
|
21 inch |
(included with KIT1) (2 21 inch sections required) |
ships same day |
KIT 1 |
192-9418
|
Pad driver |
$161.62
|
2 |
|
ships same day |
