COMBIMATSWINGO2500 Battery Assembly - Version 7

#PartDescriptionPriceReqNotesAvailability
1 192-1116 Chassis $531.94 1 usually ships 1-5 days
2 192-1131 Bracket $53.26 2 usually ships 30-75 days
3 192-0078 Screw M8 x 16mm socket head $2.44 8 ships same day
4 192-1125 Stop buffer $4.84 2 ships same day
5 192-1306 Bushing $7.03 2 usually ships 1-5 days
6 192-0347 Nut M8 hex $0.89 2 ships same day
7 192-0731 2 way connection block $7.33 2 usually ships 30-75 days
8 192-1105 Screw M4 x 20mm socket head $2.44 2 usually ships 1-5 days
9 192-1082 Grommet $2.44 2 usually ships 30-75 days
10 192-1930 Battery housing $595.39 1 usually ships 1-5 days
11 192-7097 Tie bar $70.82 1 usually ships 1-5 days
12 192-2189 Bracket $4.84 2 usually ships 1-5 days
13 192-0968 Screw KA 60 x 16 $4.40 8 ships same day
14 192-3859 Front cover $507.72 1 usually ships 1-5 days
15 192-7096 Tie bar $63.07 1 usually ships 1-5 days
16 192-2725 Centering screw $16.85 4 usually ships 1-5 days
17 192-6165 Rubber disc 28 x 13-1/2 x 4 $2.44 4 usually ships 30-75 days
18 192-7412 Washer 15/28 $3.00 4 usually ships 30-75 days
19 192-1090 Retaining ring $2.44 4 usually ships 1-5 days
20 292-0964 Foot plate Call for price 1 usually ships 30-75 days
21 192-5782 Right hand protection profile $409.38 1 usually ships 30-75 days
22 192-5781 Left hand protection profile $409.38 1 ships same day
23 192-0278 Screw M8 x 25mm socket head $0.89 4 ships same day
24 192-0079 Washer $0.89 4 ships same day
